Making 3D planning drawings with ArcGIS

Load the required data , This is the plan （ Ordinary drawings without coordinate system , Registration required ）.

CAD Prepared land use plan .

1： Right click , Find the geo registration tool, open and activate .
2： Find the drop-down options for geographic registration , Find auto correction , Cancel automatic correction .
3： Select the registration object ： Land use plan .

1： New registration control point , Select the corresponding control point （ Don't choose the wrong position ）.
2： You can see the connection table , If the control point is selected incorrectly , You can delete .
3： Click the correction tool in the geographical registration drop-down menu .
4： Output address and naming .

1： open ArcScene load TIN And plans , Right click on the plan , Find the layer properties .
2： Find the basic height .
3： Get elevation from the surface （ Customize ）.
4： The layer moves 2 A unit of .

1： Switch to the rendering toolbar .
2： Find effect , Create shadows , Then click OK .

Upper figure ： Effect drawing of three-dimensional land use planning .
