Three. JS learning project -- 3D data visualization of anti US aggression and aid Korea

Part of the scene

Experience address

https://kmyc.hongbin.xyz/

Operation instructions video

What I did （ function ）

• draco analysis glb Model Process some texture requests at the same time Reduce the pressure of loading texture at one time
• Manually control the track controller lens animation
• Multi audio splicing control
• Encapsulate the animation player Control progress switching
• Animation progress controller Sync audio Analog video experience
• useContext State sharing
• Customize multi-level right-click menu Simulate native menu experience
• Idle time to load subsequent models
• Model texture & Position dynamic switching
• echart The chart uses
• Browser adaptive units vw vmax Use ( Large area use )
• Compatible with mobile browsing
• Model destruction and animation loading
• useRef Expose method multiparty calls ( A lot of use )
• css-in-js Project practice css engine styled-component
• Incomplete requests avoid impact
• Counter cleanup not performed Subtitle playing Switch during the execution of shot switching animation Subsequent functions, etc
• Click on different models to produce different effects Click on the event monitor mouse hover The style of
• …

limited

• Performance collapse For many reasons Without on-demand rendering, the frame rate on the low configuration machine is about 30 Around the frame
• The model is not fine - First modeling
• Play the animation model on the mobile phone or high brush device, and the rendering speed is the same as 60 Frame device inconsistent

Source code address

https://gitee.com/honbingitee/kmyc

Partial logic

Render on demand

controls.addEventListener('change', () => {

	renderer.render(scene, camera);
});

Model loading

https://hongbin.blog.csdn.net/article/details/122594047

Animation controller

https://hongbin.blog.csdn.net/article/details/123662686

Model texture condition switching

/** * @description:  Load album model   Return the callback of relevant operation  * @param {number} animationIndex  Campaign index  * @param {THREE.TextureLoader} textureLoader  Texture loader  * @return {XCBack} XCBack */
export async function loadXCModel(
  animationIndex: number, textureLoader: THREE.TextureLoader
): Promise<XCBack> {

  const gltf = await window.gltfLoader.loadAsync(xcModel);
  const [model] = gltf.scene.children;
  const multiple = 5;
  model.position.y = 1.8 * multiple;

  if (animationIndex === 1) {

    model.rotateY(-Math.PI / 2);
    model.rotateX(-Math.PI / 10);
    model.rotateZ(Math.PI / 10);
  }

  const setZero = (mash: typeof model) => {

    mash.scale.x = 0;
    mash.scale.y = 0;
    mash.scale.z = 0;
  };
  setZero(model);
  /** *  Set different textures  --  Switch pictures  */
  const setMaterial = (mash: Object3D, url: string) => {

    const texture = textureLoader.load(url);
    texture.flipY = false;
    texture.encoding = 3001;
    //@ts-ignore
    const mater = mash.material.clone(); // You can't share one material  think  instance.material  Point to the same object

    mater.map = texture;
    //@ts-ignore
    mash.material = mater;
  };

  const pictures: XCBack["models"] = [];

  for (let i = 0; i < 4; i++) {

    const instance = model.clone();
    //hover tip
    instance.userData.type = ModelType["Picture"];
    instance.userData.desc = XCDesc[animationIndex]
      ? XCDesc[animationIndex][i]
      : "";

    setMaterial(
      instance,
      `${
      process.env.REACT_APP_URL}xc/${
      animationIndex}-${
      i}-y.jpg`
    );
    if (animationIndex === 1) {

      instance.position.x = (i - 1) * -5 * multiple;
      instance.position.z = -14 * multiple;
    } else if (animationIndex === 2) {

      instance.position.x = -10 * multiple;
      instance.position.z = (i - 2) * 5 * multiple;
    } else {

      instance.position.x = -10 * multiple;
      instance.position.z = (i - 1) * 5 * multiple;
    }
    pictures.push(instance);
  }

  let timer1: number;
  let count = 0;
  const range = 30;
  const show = () => {

    if (count < range) {

      pictures.forEach(item => {

        item.scale.y += multiple / range;
        item.scale.z += (multiple / range) * 1.8;
        item.scale.x += multiple / range / 10;
      });
      count++;
      timer1 = requestAnimationFrame(show);
    }
  };

  const hide = () => {

    pictures.forEach(setZero);
    count = 0;
    cancelAnimationFrame(timer1);
    requestAnimationFrame(() => {

      cancelAnimationFrame(timer1);
    });
  };

  let prevIndex = animationIndex;

  const toggle: XCBack["toggle"] = nextIndex => {

    pictures.forEach((item, index) => {

      /** * hover  Show picture introduction  */
      item.userData.type = ModelType["Picture"];
      item.userData.desc = XCDesc[nextIndex][index];

      setMaterial(
        item,
        `${
      process.env.REACT_APP_URL}xc/${
      nextIndex}-${
      index}-y.jpg`
      );
      // Rotation Angle
      if (nextIndex === 1) {

        if (prevIndex !== 1) {

          item.rotateY(-Math.PI / 2);
          item.rotateX(-Math.PI / 10);
          item.rotateZ(Math.PI / 10);
        }
      } else {

        if (prevIndex === 1) {

          item.rotateY(Math.PI / 2);
          item.rotateX(Math.PI / 10);
          item.rotateZ(Math.PI / 10);
        }
      }
      // Location
      if (nextIndex === 1) {

        item.position.x = (index - 1) * -5 * multiple;
        item.position.z = -14 * multiple;
      } else if (nextIndex === 2) {

        item.position.x = -10 * multiple;
        item.position.z = (index - 2) * 5 * multiple;
      } else {

        item.position.x = -10 * multiple;
        item.position.z = (index - 1) * 5 * multiple;
      }
    });
    prevIndex = nextIndex;
  };

  return {

    show,
    hide,
    models: pictures,
    toggle,
  };
}

Model loading also requests some textures Generate progress bar

// load 10 A texture
const loadTexture = () => {

    const textureLoader = new TextureLoader();

    for (let i = 0; i < 10; i++) {

      const index = i.toString().padStart(2, "0");
      const url = `${
      process.env.REACT_APP_URL}q/${
      i}.jpg`;
      const texture = textureLoader.load(
        url,
        _ => {

          setProgress(timeCheck(5));
        },
        undefined,
        err => {

          console.error("load texture fail:", err);
          setProgress(timeCheck(5));
        }
      );
      texture.flipY = false;
      texture.encoding = sRGBEncoding;
      addTexture(index, texture);
    }
  };

//draco Analytical model
const dracoLoader = () => {

    let prevModel = 0;
    const manager = new LoadingManager();
    manager.onProgress = (_, loaded, total) => {

      const progress = Math.floor((loaded / total) * 100);
      if (progress === 100) return setProgress(timeCheck(50 - prevModel));
      prevModel += progress / 4;
      setProgress(timeCheck(progress / 4));
    };
    // Set error message
    manager.onError = setIsLoadFail;
    // establish draco Parser
    const dracoLoader = new DRACOLoader(manager);
    dracoLoader.setDecoderConfig({
     type: "js" });
    dracoLoader.setDecoderPath(process.env.REACT_APP_URL as string);
    // gltf  loader
    const gltfLoader = new GLTFLoader(manager);
    gltfLoader.setDRACOLoader(dracoLoader);
    gltfLoader.load(mapModel, setMap);
    // No LoadingManager The loader of   If you use gltfLoader Will trigger an event change progress State causes a memory leak
    const normalGltfLoader = new GLTFLoader();
    normalGltfLoader.setDRACOLoader(dracoLoader);
    window.gltfLoader = normalGltfLoader;
  };

/** *  Progress growth detection  * @param {number} increase  The value of growth  * @param {number} prev state Original value  * @return {number} newValue */
 const timeCheck = (increase: number) => (prev: number) => {

   if (increase + prev < 100) return prev + increase;
   // >= 100  Test time
   if (Date.now() - enterTime > maxLoadTime) return 100;
   //time < maxLoadTime
   timer = setTimeout(() => {

     setProgress(100);
   }, maxLoadTime - (Date.now() - enterTime));
   // Show skip button
   setIsCanJump(true);
   return prev;
 };

Model scaling animation

let timer: number;
let i = 0;
const r = () => {

 if (i < 15) {

   timer = requestAnimationFrame(r);
 }
 for (const item of iconScene.children) {

   item.scale.x += 0.03;
   item.scale.y += 0.03;
   item.scale.z += 0.03;
 }
 i++;
};
r();
