Raspberry pie Kali system HDMI modifies screen resolution

Raspberry pie brush kali After the system is powered on, connect to HDMI On the screen , I found that the screen resolution is too high to see anything clearly , Just like this.



Later, I found a lot of information on the Internet and said it was setting -> Modify the resolution in the display , But even if I log in root The resolution of the account cannot be modified .

Later, combined with online materials , Then I fumbled for it , eureka HDMI How to adjust the screen resolution

1. Raspberry pie SD Unplug the card and plug it into the computer

2. open config.txt file （ Just installed and not run kali There is no such document , It is recommended to run once ）

3. Add a command , You can also directly modify the original instructions in the file , But remember to # Remove the number

my HDMI The screen resolution is 480*320 Of , But I like to make it bigger , So set it to 1.5 Multiple size

framebuffer_width=720
framebuffer_height=480

hdmi_group=2
hdmi_mode=3
hdmi_ignore_edid=0xa5000080

hdmi_group and hdmi_mode The value of corresponds to the resolution you want to adjust . Another item “hdmi_ignore_edid”, Ordered raspberry pie not to detect HDMI Any information about the device , Output only at the resolution we specify . If not , Raspberry pie may still detect HDMI Device resolution , As a result, the set resolution is invalid .
Remember to remove the before the command # Number

Here are CEA Specified TV specification resolution . These resolutions hdmi_group=1.

hdmi_mode=1    VGA

hdmi_mode=2    480p 60Hz

hdmi_mode=3    480p 60Hz  H

hdmi_mode=4    720p 60Hz

hdmi_mode=5    1080i 60Hz

hdmi_mode=6    480i 60Hz

hdmi_mode=7    480i 60Hz  H

hdmi_mode=8    240p 60Hz

hdmi_mode=9    240p 60Hz  H

hdmi_mode=10   480i 60Hz  4x

hdmi_mode=11   480i 60Hz  4x H

hdmi_mode=12   240p 60Hz  4x

hdmi_mode=13   240p 60Hz  4x H

hdmi_mode=14   480p 60Hz  2x

hdmi_mode=15   480p 60Hz  2x H

hdmi_mode=16   1080p 60Hz

hdmi_mode=17   576p 50Hz

hdmi_mode=18   576p 50Hz  H

hdmi_mode=19   720p 50Hz

hdmi_mode=20   1080i 50Hz

hdmi_mode=21   576i 50Hz

hdmi_mode=22   576i 50Hz  H

hdmi_mode=23   288p 50Hz

hdmi_mode=24   288p 50Hz  H

hdmi_mode=25   576i 50Hz  4x

hdmi_mode=26   576i 50Hz  4x H

hdmi_mode=27   288p 50Hz  4x

hdmi_mode=28   288p 50Hz  4x H

hdmi_mode=29   576p 50Hz  2x

hdmi_mode=30   576p 50Hz  2x H

hdmi_mode=31   1080p 50Hz

hdmi_mode=32   1080p 24Hz

hdmi_mode=33   1080p 25Hz

hdmi_mode=34   1080p 30Hz

hdmi_mode=35   480p 60Hz  4x

hdmi_mode=36   480p 60Hz  4xH

hdmi_mode=37   576p 50Hz  4x

hdmi_mode=38   576p 50Hz  4x H

hdmi_mode=39   1080i 50Hz reduced blanking

hdmi_mode=40   1080i 100Hz

hdmi_mode=41   720p 100Hz

hdmi_mode=42   576p 100Hz

hdmi_mode=43   576p 100Hz H

hdmi_mode=44   576i 100Hz

hdmi_mode=45   576i 100Hz H

hdmi_mode=46   1080i 120Hz

hdmi_mode=47   720p 120Hz

hdmi_mode=48   480p 120Hz

hdmi_mode=49   480p 120Hz H

hdmi_mode=50   480i 120Hz

hdmi_mode=51   480i 120Hz H

hdmi_mode=52   576p 200Hz

hdmi_mode=53   576p 200Hz H

hdmi_mode=54   576i 200Hz

hdmi_mode=55   576i 200Hz H

hdmi_mode=56   480p 240Hz

hdmi_mode=57   480p 240Hz H

hdmi_mode=58   480i 240Hz

hdmi_mode=59   480i 240Hz H

H means 16:9variant (of a normally 4:3 mode).

2x means pixeldoubled (i.e. higher clock rate, with each pixel repeated twice)

4x means pixelquadrupled (i.e. higher clock rate, with each pixel repeated four times)

Here is the resolution used by the computer monitor . These resolutions hdmi_group=2.

hdmi_mode=1    640x350  85Hz

hdmi_mode=2    640x400  85Hz

hdmi_mode=3    720x400  85Hz

hdmi_mode=4    640x480  60Hz

hdmi_mode=5    640x480  72Hz

hdmi_mode=6    640x480  75Hz

hdmi_mode=7    640x480  85Hz

hdmi_mode=8    800x600  56Hz

hdmi_mode=9    800x600  60Hz

hdmi_mode=10   800x600  72Hz

hdmi_mode=11   800x600  75Hz

hdmi_mode=12   800x600  85Hz

hdmi_mode=13   800x600  120Hz

hdmi_mode=14   848x480  60Hz

hdmi_mode=15   1024x768 43Hz  DO NOT USE

hdmi_mode=16   1024x768 60Hz

hdmi_mode=17   1024x768 70Hz

hdmi_mode=18   1024x768 75Hz

hdmi_mode=19   1024x768 85Hz

hdmi_mode=20   1024x768 120Hz

hdmi_mode=21   1152x864 75Hz

hdmi_mode=22   1280x768        reduced blanking

hdmi_mode=23   1280x768 60Hz

hdmi_mode=24   1280x768 75Hz

hdmi_mode=25   1280x768 85Hz

hdmi_mode=26   1280x768 120Hz reduced blanking

hdmi_mode=27   1280x800        reduced blanking

hdmi_mode=28   1280x800 60Hz

hdmi_mode=29   1280x800 75Hz

hdmi_mode=30   1280x800 85Hz

hdmi_mode=31   1280x800 120Hz reduced blanking

hdmi_mode=32   1280x960 60Hz

hdmi_mode=33   1280x960 85Hz

hdmi_mode=34   1280x960 120Hz reduced blanking

hdmi_mode=35   1280x1024 60Hz

hdmi_mode=36   1280x1024 75Hz

hdmi_mode=37   1280x1024 85Hz

hdmi_mode=38   1280x1024 120Hz reduced blanking

hdmi_mode=39   1360x768 60Hz

hdmi_mode=40   1360x768 120Hz reduced blanking

hdmi_mode=41   1400x1050       reduced blanking

hdmi_mode=42   1400x1050 60Hz

hdmi_mode=43   1400x1050 75Hz

hdmi_mode=44   1400x1050 85Hz

hdmi_mode=45   1400x1050 120Hz reduced blanking

hdmi_mode=46   1440x900        reduced blanking

hdmi_mode=47   1440x900 60Hz

hdmi_mode=48   1440x900 75Hz

hdmi_mode=49   1440x900 85Hz

hdmi_mode=50   1440x900 120Hz reduced blanking

hdmi_mode=51   1600x1200 60Hz

hdmi_mode=52   1600x1200 65Hz

hdmi_mode=53   1600x1200 70Hz

hdmi_mode=54   1600x1200 75Hz

hdmi_mode=55   1600x1200 85Hz

hdmi_mode=56   1600x1200 120Hz reduced blanking

hdmi_mode=57   1680x1050       reduced blanking

hdmi_mode=58   1680x1050 60Hz

hdmi_mode=59   1680x1050 75Hz

hdmi_mode=60   1680x1050 85Hz

hdmi_mode=61   1680x1050 120Hz reduced blanking

hdmi_mode=62   1792x1344 60Hz

hdmi_mode=63   1792x1344 75Hz

hdmi_mode=64   1792x1344 120Hz reduced blanking

hdmi_mode=65   1856x1392 60Hz

hdmi_mode=66   1856x1392 75Hz

hdmi_mode=67   1856x1392 120Hz reduced blanking

hdmi_mode=68   1920x1200       reduced blanking

hdmi_mode=69   1920x1200 60Hz

hdmi_mode=70   1920x1200 75Hz

hdmi_mode=71   1920x1200 85Hz

hdmi_mode=72   1920x1200 120Hz reduced blanking

hdmi_mode=73   1920x1440 60Hz

hdmi_mode=74   1920x1440 75Hz

hdmi_mode=75   1920x1440 120Hz reduced blanking

hdmi_mode=76   2560x1600       reduced blanking

hdmi_mode=77   2560x1600 60Hz

hdmi_mode=78   2560x1600 75Hz

hdmi_mode=79   2560x1600 85Hz

hdmi_mode=80   2560x1600 120Hz reduced blanking

hdmi_mode=81   1366x768 60Hz

hdmi_mode=82   1080p    60Hz

hdmi_mode=83   1600x900        reduced blanking

hdmi_mode=84   2048x1152       reduced blanking

hdmi_mode=85   720p     60Hz

hdmi_mode=86   1366x768        reduced blanking

4. Modify config.txt After saving , take SD Just put the card back on the raspberry pie



Obviously a lot clearer
