Applet Bluetooth connection low power device (ble) record

First step Check whether Bluetooth is authorized Initialize Bluetooth after authorization Get local Bluetooth status Enable listening for Bluetooth enable / disable events If you don't call openBluetoothAdapter Method The following cannot be done

In the code bluetooth Some common methods for encapsulation It will be written at the bottom

bluetooth.getBluetoothSetting().then(() => {
      // Authorized   Initialize Bluetooth module
      wx.openBluetoothAdapter({
        success: () => {},
        fail: err => bluetooth.errorCodeToStr(err),
        complete: () => {
          wx.hideLoading()
          this.setData({
            bluetoothInit: true
          })
          //  Get the status of the native Bluetooth adapter .
          wx.getBluetoothAdapterState().then(res => {
            this.setData({
              bluetoothAvailable: res.available,
            })
          }).catch(err => bluetooth.errorCodeToStr(err))
          //  Monitor Bluetooth adapter status change events   Turn on Bluetooth
          wx.onBluetoothAdapterStateChange((res) => {
            let page = getCurrentPages()
            if (page[page.length - 1].route != 'pages/index/index') return
            wx.showToast({
              title: ' Bluetooth has ' + (res.available ? ' Turn on ' : ' close '),
              icon: 'none'
            })
            this.setData({
              bluetoothAvailable: res.available,
            })
          })
        }
      })
    }).catch(err => {
      wx.showToast({
        title: err,
        icon: 'none'
      })
    })

The second step Search for low-power Bluetooth devices And stop searching Add the searched device to the list Click the list to select the Bluetooth device you want to connect （ The click event in the list is not written Just write it yourself ）

let timer=null
//  Start searching for Bluetooth devices  10 Stop automatically after seconds   You can also stop the search manually
  starSearch() {
    wx.hideLoading()
    wx.startBluetoothDevicesDiscovery({
      allowDuplicatesKey: false
    }).then(res => {
      this.setData({
        status: 1
      })
      //  Timed end of search
      timer = setTimeout(() => {
        this.stopSearch()
      }, 10000)
    }).catch(err => bluetooth.errorCodeToStr(err))
    //  Listen for events when a new device is found   Add to list
    wx.onBluetoothDeviceFound((res) => {
      var devices = res.devices[0];
      if (devices.name) {
        this.setData({
          list: [...this.data.list, devices]
        })
      }
    })
  },
  //  stop searching ( It can be called manually )
  stopSearch() {
    wx.hideLoading()
   // Clear the timer
    clearTimeout(timer)
   // Cancel listening for the event of finding a new device
    wx.offBluetoothDeviceFound()
    // Stop searching for nearby Bluetooth peripherals   Judge the number of equipment and give a prompt
    wx.stopBluetoothDevicesDiscovery().then(res => {
      let status = (this.data.list.length < 1 ? 2 : 3)
      this.setData({
        status: status
      })
      if (status == 2) {
        wx.showModal({
          title: ' Tips ',
          content: ' No device detected , Please turn on the device and try again ~',
          showCancel: false
        })
      }
    }).catch(err => bluetooth.errorCodeToStr(err))
  },

The third step   Create a Bluetooth connection to get the required information deviceId（ Get when a device is searched ） serviceId（isPrimary=true the uuid）,characteristicId（ This is the need for characteristics in write by true when It is used for writing uuid If you need to monitor the reported information Need to choose notify by true Of uuid） It's a concept Refer to the official documents for details and judge in combination with the information printed on your console

When the Bluetooth connection is successful, the data of the Bluetooth device can be transferred Save to cache or other location Convenient for the next direct trial

original text ：

createBLEConnection Connect Bluetooth low-power devices .

If the applet has searched a Bluetooth device before , And successfully established the connection , You can directly enter the information obtained by previous search deviceId Try connecting the device directly , There is no need to search again .

//  Create a Bluetooth connection
  createMachineLink() {
    //  Before connecting   Disconnect from other Bluetooth low-power devices
    wx.showLoading({
      title: ' Connecting ...',
      mask: true
    })
    //  Listen for disconnection
    wx.onBLEConnectionStateChange((res) => {
      if (!res.connected)
        this.setData({
          isLink: res.connected,
        })
    })

    wx.createBLEConnection({
      deviceId: this.data.deviceId,
      timeout: 5000,
    }).then(() => {
      //  Get all services of Bluetooth low-power devices  (service)
      wx.getBLEDeviceServices({
        deviceId: this.data.deviceId
      }).then(servicesData => {
        this.setData({
          serviceId: servicesData.services[0].uuid
        }, () => {
          //  Get all the features in a service of Bluetooth low-power device  (characteristic)
          wx.getBLEDeviceCharacteristics({
            deviceId: this.data.deviceId,
            serviceId: this.data.serviceId,
          }).then(res => {
            wx.setStorageSync('leaveStatus', 'link')
            wx.showToast({
              title: ' Successful connection ',
            })
            this.setData({
              isLink: true,
              writeCharacteristicId: res.characteristics.find(item => item.properties.write == true).uuid,
              notifyCharacteristicId: res.characteristics.find(item => item.properties.notify == true).uuid
            }, () => this.notifyBluetoothListener())
          }).catch(err => bluetooth.errorCodeToStr(err))
        })
      }).catch(err => bluetooth.errorCodeToStr(err))
    }).catch(err => bluetooth.errorCodeToStr(err))
  },

Step four     Write data My method of direct encapsulation here You can refer to （ This needs to be passed in 10 byte Of 16 Base string ） This is just a reference

bluetooth.writeData(this.data.deviceId, this.data.serviceId, this.data.writeCharacteristicId, '044000')

// encapsulation
  //  Write data
  writeData(deviceId, serviceId, characteristicId, value) {
    wx.writeBLECharacteristicValue({
      deviceId,
      serviceId,
      characteristicId,
      value: this.createBuffer(value),
    }).then(res => {
      setTimeout(() => {
        wx.hideLoading()
      }, 700)
    }).catch(err => this.errorCodeToStr(err))
  },
  //  establish 10 position  0x00 16 Hexadecimal data
  createBuffer(num) {
    let buffer = new ArrayBuffer(10);
    let dataView = new DataView(buffer);
    //  Fixed head
    dataView.setUint8(0, 0x0D);
    dataView.setUint8(1, 0x02);
    //  Fix the head and tail
    dataView.setUint8(8, 0x0D);
    dataView.setUint8(9, 0x03);
    for (let i in num) {
      dataView.setUint8(parseInt(i) + 2, ('0x' + num[i].charCodeAt().toString(16)));
    }
    return dataView.buffer
  },

Step five Listen to the information reported by Bluetooth Decode and process accordingly

//  monitor   Equipment report
  notifyBluetoothListener() {
    wx.showLoading({
      title: ' Get status ...',
      mask: true
    })
    //   Enable Bluetooth low-power device when the eigenvalue changes  notify  function
    wx.notifyBLECharacteristicValueChange({
      state: true,
      deviceId: this.data.deviceId,
      serviceId: this.data.serviceId,
      characteristicId: this.data.notifyCharacteristicId,
    }).then(res => {
      //  Enabled successfully   Give orders   obtain   Equipment status
      bluetooth.writeData(this.data.deviceId, this.data.serviceId, this.data.writeCharacteristicId, '018000')
    }).catch(err => bluetooth.errorCodeToStr(err))

    //  You must first enable  wx.notifyBLECharacteristicValueChange  To listen to the device  characteristicValueChange  event
    wx.onBLECharacteristicValueChange((res) => {
      setTimeout(() => {
        this.setData({
          writeType: false
        })
      }, 1000)

      if (res.value.length >= 11) {
        bluetooth.closeBLEConnection(this.data.deviceId)
        wx.showToast({
          title: ' Unknown error ',
        })
        return
      }
      this.handleValueChange(bluetooth.ab2hex(res.value))
    })
  },
  //  Report result processing
  handleValueChange(str) {
    //  Remove the fixed head and fixed tail
    let hex = str.substring(4,str.length-4)
    hex = bluetooth.hexCharCodeToStr(hex)
    if (!hex) {
      wx.showToast({
        title: ' Unknown error ',
      })
      return
    }
    let status = Number('0x' + (hex.substring(0, 2)))

    if (!status) {
      bluetooth.closeBLEConnection(this.data.deviceId)
      wx.showToast({
        title: ' Unknown error ',
      })
      return
    }

    this.setData({
      isRun: (status >> 6) & 1, // Is it running
      isHot: (status & 1), // heating
      speed: (status >> 2) & 3, // Speed
      mode: (status >> 4) & 3, // Pattern
    })
  },

here The method used in the encapsulated code above

module.exports = {
  //  establish 10 position  0x00 16 Hexadecimal data
  createBuffer(num) {
    let buffer = new ArrayBuffer(10);
    let dataView = new DataView(buffer);
    //  Fixed head
    dataView.setUint8(0, 0x0D);
    dataView.setUint8(1, 0x02);
    //  Fix the head and tail
    dataView.setUint8(8, 0x0D);
    dataView.setUint8(9, 0x03);
    for (let i in num) {
      dataView.setUint8(parseInt(i) + 2, ('0x' + num[i].charCodeAt().toString(16)));
    }
    return dataView.buffer
  },
  //  Write data
  writeData(deviceId, serviceId, characteristicId, value) {
    wx.writeBLECharacteristicValue({
      deviceId,
      serviceId,
      characteristicId,
      value: this.createBuffer(value),
    }).then(res => {
      setTimeout(() => {
        wx.hideLoading()
      }, 700)
    }).catch(err => this.errorCodeToStr(err))
  },
  //  Disconnect Bluetooth
  closeBLEConnection(deviceId, type) {
    wx.closeBLEConnection({
      deviceId: deviceId,
      success: () => {
        if (type)
          wx.showToast({
            title: ' disconnect ',
            icon: 'none'
          })
      },
      fail: err => this.errorCodeToStr(err, type)
    })
  },
  // Bluetooth authorization query
  getBluetoothSetting() {
    return new Promise((resolve, reject) => {
      wx.getSetting().then(res => {
        if (!res.authSetting['scope.bluetooth']) {
          this.scopeBluetooth().then(data => {
            resolve(data)
          }).catch(err => reject(err))
        } else {
          resolve(res.authSetting)
        }
      }).catch(err => reject('getSetting error'))
    })
  },
  // Apply for Bluetooth authorization
  scopeBluetooth() {
    return new Promise((resolve, reject) => {
      wx.authorize({
        scope: 'scope.bluetooth',
        success(res) {
          resolve(res)
        },
        fail(err) {
          wx.showModal({
            title: ' Tips ',
            content: ' Please authorize Bluetooth , In order to use the equipment ',
            success(res) {
              if (res.cancel) {
                reject(' Unauthorized Bluetooth ')
                return
              }
              wx.openSetting({
                success(data) {
                  if (data.authSetting['scope.bluetooth']) {
                    resolve(data.authSetting)
                  } else {
                    reject(' Unauthorized Bluetooth ')
                  }
                }
              })
            }
          })
        }
      })
    })
  },
  //  Unified processing of Bluetooth errors
  errorCodeToStr(err, type) {
    console.log(err)

    if (!err.errCode) {
      console.log(err.errMsg)
      return
    }
    if (type) return
    wx.showToast({
      title: this.codeToStr[err.errCode],
      icon: 'none'
    })
  },
  codeToStr: {
    "0": " normal ",
    "-1": " Connected ",
    "10000": " Bluetooth adapter not initialized ",
    "10001": " The Bluetooth adapter is currently unavailable ",
    "10002": " The specified device was not found ",
    "10003": " The connection fails ",
    "10004": " The specified service was not found ",
    "10005": " The specified feature was not found ",
    "10006": " The current connection has been disconnected ",
    "10007": " This operation is not supported by the current feature ",
    "10008": " All other exceptions reported by the system ",
    "10009": "Android  System specific , The system version is lower than  4.3  I won't support it  BLE",
    "10012": " Connection timeout ",
    "10013": " Connect  deviceId  Empty or incorrectly formatted ",
  },
  // ArrayBuffer turn 16 Base string
  ab2hex(buffer) {
    let hexArr = Array.prototype.map.call(
      new Uint8Array(buffer),
      function (bit) {
        return ('00' + bit.toString(16)).slice(-2)
      }
    )
    return hexArr.join('');
  },
  // ArrayBuffer turn 16 Hexadecimal string to 16 Hexadecimal Numbers
  hexCharCodeToStr(hexCharCodeStr) {
    var trimedStr = hexCharCodeStr.trim();
    var rawStr = trimedStr.substr(0, 2).toLowerCase() === "0x" ? trimedStr.substr(2) : trimedStr;
    var len = rawStr.length;
    if (len % 2 !== 0) {
      alert(" There are illegal characters !");
      return "";
    }
    var curCharCode;
    var resultStr = [];
    for (var i = 0; i < len; i = i + 2) {
      curCharCode = parseInt(rawStr.substr(i, 2), 16);
      resultStr.push(String.fromCharCode(curCharCode));
    }
    return resultStr.join("");
  },
}

This article Just a rough record   So that I can have some experience in similar projects again   I hope to provide some help to those who read this article
