It's used at work oracle Officially encapsulated tools （rman_xttconvert） Do the migration , In fact, cross platform migration can also be done manually . For complex scenes , The migration can be customized manually .

One 、 Full transfer table space

If the database is in 1T within , Downtime operation , It can be directly used once RMAN Backup , Transfer the data file to the target platform host . You need to make the migrated tablespace read-only .

-- Confirm whether the components are consistent

SET lines 90 NUMWIDTH 12 PAGES 10000 LONG 2000000000ALTER SESSION SET nls_date_format='YYYY-MM-DD HH24:MI:SS';COL version FORMAT a12COL comp_id FORMAT a8COL schema LIKE versionCOL comp_name FORMAT a35COL status FORMAT a12SELECT comp_id,schema,status,version,comp_nameFROM dba_registryORDER BY 1;

-- Determine platform ID

col PLATFORM_NAME for a30col ENDIAN_FORMAT for a30SELECT D.PLATFORM_NAME, ENDIAN_FORMAT,d.platform_idFROM V$TRANSPORTABLE_PLATFORM TP, V$DATABASE DWHERE TP.PLATFORM_NAME = D.PLATFORM_NAME;

-- The production library confirms whether there is a user table in the system table space

User-Owned Tables Residing in the SYSTEM or SYSAUX Tablespacesselect owner, segment_name, segment_typefrom dba_segmentswhere tablespace_name in ('SYSTEM', 'SYSAUX')and owner not in(select namefrom system.logstdby$skip_supportwhere action=0);

-- Original library tablespace self-contained check

declarechecklist varchar2(4000);i number := 0;beginfor ts in(select tablespace_namefrom dba_tablespaceswhere tablespace_name not in ('SYSTEM','SYSAUX','AUDITTBS') and contents = 'PERMANENT')loopif (i=0) thenchecklist := ts.tablespace_name;elsechecklist := checklist||','||ts.tablespace_name;end if;i := 1;end loop;dbms_tts.transport_set_check(checklist,TRUE,TRUE);end;/select * from transport_set_violations;

-- The source library sets the tablespace as read-only

alter tablespace TESTXTT read only;alter tablespace TESTXTTIDX read only;

-- The source library converts the table space to the byte order of the target platform

CONVERT TABLESPACE TESTXTT,TESTXTTIDXTO PLATFORM 'Linux x86 64-bit'FORMAT='/xttsoft/backupdir/%N_%f.dbf' parallelism 3;

-- The target library puts the backed up data files into the corresponding empty directory of the target

mv /xttsoft/backupdir/TESTXTT* $ORACLE_BASE/oradata/tdb/

Import metadata from the target library

impdp userid=\"sys/Passw0rd as sysdba\" directory=exp_dir logfile=tts_imp.log \network_link=from_old transport_full_check=no \transport_tablespaces=TESTXTT,TESTXTTIDX \transport_datafiles='/oracle/app/oracle/oradata/testdb/TESTXTT_5.dbf','/oracle/app/oracle/oradata/testdb/TESTXTTIDX_6.dbf'

Two 、 Incremental cross platform transfer of tablespaces

The applicable database is relatively large , Short downtime , Just shut down at the last increment .

-- Source library turns on block tracking , And make sure to increase the number of incremental backup records . You have to set , Otherwise, the increment time is as long as the full amount time .

select * From v$block_change_tracking;alter system set "_bct_bitmaps_per_file"=100;alter database enable block change tracking using file '/arch/change_tracking.f'select * from v$block_change_tracking;alter system set large_pool_size=2G;

-- Generate full backup and full recovery statements , Source side execution

select RMAN_SCRIPTFrom (select '1' step,tablespace_name,file_id,'backup as copy tag ''prepare'' datafile ' || FILE_ID ||' format ''/xttsoft/backupdir/' || TABLESPACE_NAME || '_' ||file_id || '.enmo''; #scn:' ||dbms_flashback.get_system_change_number rman_scriptfrom dba_data_fileswhere tablespace_name in ('TESTXTT', 'TESTXTTIDX')union allselect '2' step,tablespace_name,file_id,'convert from platform ''Linux x86 64-bit'' datafile ''/xttsoft/backupdir/' ||tablespace_name || '_' || file_id ||'.enmo'' format ''/oracle/app/oracle/oradata/testdb/' ||TABLESPACE_NAME || '_' || file_id || '''; #scn:' ||dbms_flashback.get_system_change_number rman_scriptfrom dba_data_fileswhere tablespace_name in ('TESTXTT', 'TESTXTTIDX'))order by step;

-- Script generated backup , Source side execution

backup as copy tag 'prepare' datafile 5 format '/xttsoft/backupdir/TESTXTT_5.enmo'; #scn:1173499backup as copy tag 'prepare' datafile 6 format '/xttsoft/backupdir/TESTXTTIDX_6.enmo'; #scn:1173499

-- Script generated transformation , Target side execution

convert from platform 'Linux x86 64-bit' datafile '/xttsoft/backupdir/TESTXTT_5.enmo' format '/oracle/app/oracle/oradata/testdb/TESTXTT_5'; #scn:1173499convert from platform 'Linux x86 64-bit' datafile '/xttsoft/backupdir/TESTXTTIDX_6.enmo' format '/oracle/app/oracle/oradata/testdb/TESTXTTIDX_6'; #scn:1173499

-- For the first time

backup as copy tag 'prepare' datafile 5 format '/xttsoft/backupdir/TESTXTT_5.enmo'; #scn:1173499backup as copy tag 'prepare' datafile 6 format '/xttsoft/backupdir/TESTXTTIDX_6.enmo'; #scn:1173499

-- First full recovery

convert from platform 'Linux x86 64-bit' datafile '/xttsoft/backupdir/TESTXTT_5.enmo' format '/oracle/app/oracle/oradata/testdb/TESTXTT_5'; #scn:1173499convert from platform 'Linux x86 64-bit' datafile '/xttsoft/backupdir/TESTXTTIDX_6.enmo' format '/oracle/app/oracle/oradata/testdb/TESTXTTIDX_6'; #scn:1173499

-- Incremental composite stored procedure , Create... On the target side , Subsequent incremental synthesis will use

create or replace procedure rollforward(p_datafile_name varchar2,p_incr_file_name varchar2,p_fnumber number) asouthandle varchar2(512);outtag varchar2(30);done boolean;failover boolean;devtype VARCHAR2(512);BEGINDBMS_OUTPUT.put_line('Entering RollForward');-- Now the rolling forward.devtype := sys.dbms_backup_restore.deviceAllocate;sys.dbms_backup_restore.applySetDatafile(check_logical => FALSE,cleanup => FALSE);DBMS_OUTPUT.put_line('After applySetDataFile');sys.dbms_backup_restore.applyDatafileTo(dfnumber => p_fnumber,toname => p_datafile_name,fuzziness_hint => 0,max_corrupt => 0,islevel0 => 0,recid => 0,stamp => 0);DBMS_OUTPUT.put_line('Done: applyDataFileTo');DBMS_OUTPUT.put_line('Done: applyDataFileTo');-- Restore Set Piecesys.dbms_backup_restore.restoreSetPiece(handle => p_incr_file_name,tag => null,fromdisk => true,recid => 0,stamp => 0);DBMS_OUTPUT.put_line('Done: RestoreSetPiece');-- Restore Backup Piecesys.dbms_backup_restore.restoreBackupPiece(done => done,params => null,outhandle => outhandle,outtag => outtag,failover => failover);DBMS_OUTPUT.put_line('Done: RestoreBackupPiece');sys.dbms_backup_restore.restoreCancel(TRUE);sys.dbms_backup_restore.deviceDeallocate;END;/

-- Incremental backup

select 'backup incremental from scn 1173499 tag tts_incr_update tablespace '''||TABLESPACE_NAME||''' format ''/xttsoft/backupdir/incr_%d_%T_%U''; #scn:'||dbms_flashback.get_system_change_number rman_inc_script from dba_data_files where tablespace_name in ('TESTXTT','TESTXTTIDX') order by tablespace_name,file_name;backup incremental from scn 1173499 tag tts_incr_update tablespace 'TESTXTT' format '/xttsoft/backupdir/incr_%d_%T_%U'; #scn:1173657backup incremental from scn 1173499 tag tts_incr_update tablespace 'TESTXTTIDX' format '/xttsoft/backupdir/incr_%d_%T_%U'; #scn:1173657

-- Incremental synthesis

select 'exec rollforward(''/oracle/app/oracle/oradata/testdb/' ||t3.TABLESPACE_NAME || '_' || file_id || ''',''' || t1.HANDLE ||''',' || t2.FILE# || ')'From v$backup_piece_details t1left join v$backup_datafile t2on (t1.RECID = t2.RECID)left join dba_data_files t3on (t2.FILE# = t3.file_id)where t2.INCREMENTAL_CHANGE# = 1173499and t1.HANDLE not like '/xttsoft/backupdir/incr_TDB_0_%'order by t1.COMPLETION_TIME desc;

-- The target side performs incremental synthesis , Every time you log in sqlplus To perform a , somewhat BUG

exec rollforward('/oracle/app/oracle/oradata/testdb/TESTXTT_5','/xttsoft/backupdir/incr_TDB_20220421_420rgc01_1_1',5)exec rollforward('/oracle/app/oracle/oradata/testdb/TESTXTTIDX_6','/xttsoft/backupdir/incr_TDB_20220421_440rgc06_1_1',6)

-- The source library sets the tablespace as read-only

alter tablespace TESTXTT read only;alter tablespace TESTXTTIDX read only;

--readonly Post incremental backup

select 'backup incremental from scn 1173657 tag tts_incr_update tablespace '''||TABLESPACE_NAME||''' format ''/xttsoft/backupdir/incr_%d_%f_%T_%U''; #scn:'||dbms_flashback.get_system_change_number rman_inc_script from dba_data_files where tablespace_name in ('TESTXTT','TESTXTTIDX') order by tablespace_name,file_name;backup incremental from scn 1173657 tag tts_incr_update tablespace 'TESTXTT' format '/xttsoft/backupdir/incr_%d_%T_%U'; #scn:1174501backup incremental from scn 1173657 tag tts_incr_update tablespace 'TESTXTTIDX' format '/xttsoft/backupdir/incr_%d_%T_%U'; #scn:1174501

--readonly Post incremental synthesis

exec rollforward('/oracle/app/oracle/oradata/testdb/TESTXTT_5','/xttsoft/backupdir/incr_TDB_20220421_423rgc01_1_1',5)exec rollforward('/oracle/app/oracle/oradata/testdb/TESTXTTIDX_6','/xttsoft/backupdir/incr_TDB_20220421_442rgc06_1_1',6)

-- Import metadata

impdp userid=\"sys/Passw0rd as sysdba\" directory=exp_dir logfile=tts_imp.log \network_link=from_old transport_full_check=no \transport_tablespaces=TESTXTT,TESTXTTIDX \transport_datafiles='/oracle/app/oracle/oradata/testdb/TESTXTT_5','/oracle/app/oracle/oradata/testdb/TESTXTTIDX_6'
