HCIP2---第一天实验

[r5]int g0/0/0
[r5-GigabitEthernet0/0/0]ip add 10.1.1.9 30
[r5-GigabitEthernet0/0/0]int g0/0/1
[r5-GigabitEthernet0/0/1]ip add 10.1.1.6 30
[r5]ip route-static 10.1.1.4 30 10.1.1.5
[r5]ip route-static 10.1.1.8 30 10.1.1.10
[r5]ip route-static 10.1.1.0 30 10.1.1.5
[r5]ip route-static 10.1.1.12 30 10.1.1.10
[r5]ip route-static 10.1.1.16 30 10.1.1.5
[r5]ip route-static 10.1.1.16 30 10.1.1.10



r5]dhcp en
[r5]dhcp enable
Info: The operation may take a few seconds. Please wait for a moment.done.
[r5]ip pool a
Info: It’s successful to create an IP address pool.
[r5-ip-pool-a]q
[r5-GigabitEthernet0/0/2]ip add 10.1.1.65 28
[r5-GigabitEthernet0/0/2]int g4/0/0
[r5-GigabitEthernet4/0/0]ip add 10.1.1.81 28
[r5-GigabitEthernet4/0/0]q
[r5]ip pool a
[r5-ip-pool-a]gatew
[r5-ip-pool-a]gateway-list 10.1.1.65
[r5-ip-pool-a]netw
[r5-ip-pool-a]network 10.1.1.64 mask 28
[r5-ip-pool-a]static-bind ip-address 10.1.1.70 mac-address 5498-98c4-6891
[r5-ip-pool-a]q
[r5]int g0/0/2
[r5-GigabitEthernet0/0/2]dhcp select global
[r5-GigabitEthernet0/0/2]
[r5-GigabitEthernet0/0/2]q
[r5]ip pool a
[r5-ip-pool-a]q
[r5]int g4/0/0
[r5-GigabitEthernet4/0/0]dhcp select in
[r5-GigabitEthernet4/0/0]dhcp select interface .
[r5-GigabitEthernet4/0/0]dhcp server dns-list 8.8.8.8
