ROS2放弃指南5:创建ros2的topic
2022-04-21 17:07:00 【陈傻鱼】
| 功能包类型 | 用法 |
|---|---|
| ament_python | 适用于python程序 |
| cmake | 适用于C++ |
| ament_cmake | 适用于C++程序,是cmake的增强版 |
| 功能包相关指令 | 含义 |
|---|---|
| create | 创建一个新的 ROS2 包 |
| executables | 输出包特定可执行文件的列表 |
| list | 输出可用包的列表 |
| prefix | 输出包的前缀路径 |
| xml | 输出包清单或特定标签的 XML |
ros2 pkg create <package-name> --build-type {
cmake,ament_cmake,ament_python} --dependencies <依赖名字>
ros2 pkg executables // 列出所有功能包的可执行文件
ros2 pkg executables turtlesim // 列出某个功能包的可执行文件
rosdep install --from-paths src --ignore-src -rosdistro=dashing -y
rosdep install -y --from-paths src --ignore-src --rosdistro $ROS_DISTRO
// 只编译一个包
colcon build --packages-select YOUR_PKG_NAME
// 不编译测试单元
colcon build --packages-select YOUR_PKG_NAME --cmake-args -DBUILD_TESTING=0
// 建立工作空间和功能包
mkdir -p ~/test-ros2-launch/src
cd ~/test-ros2-launch/src
ros2 pkg create fishbot_description --build-type ament_python
// 建立URDF文件
cd fishbot_description && mkdir urdf
cd urdf
touch fishbot_base.urdf
cd ../
mkdir launch
cd launch
touch display_rviz2.launch.py
colcon build
source install/setup.bash
ros2 launch fishbot_description display_rviz2.launch.py
版权声明
本文为[陈傻鱼]所创,转载请带上原文链接,感谢
https://blog.csdn.net/qq_45113070/article/details/124321755
