Revit secondary development - creating elevation (phase 8)

In this issue, we will follow the modeling steps to explain how to use secondary development to create elevation .

1. Create levels .（ I won't copy the first pile of templates here .）

  Level ll = Level.Create(doc,10.00/304.8);

This line of code means in doc Creates one in 10 Mm elevation , The reason for dividing by 304.8 Because this language and software were invented by foreigners , Its unit is feet ,304.8 Is the conversion relationship between feet and millimeters .

（ Reference books or online code write Level ll = doc.Create.NewLevel(100.0); This is also right, but 2016 Previous edition API,2016 This writing method will no longer be used after version .）

Using this method, we create the elevation we want , Now look at the effect ：

We can see revit Automatically created a 10 Mm elevation , But no view was created . So we also need to create views .

2. Create view .

         Level ll = Level.Create(doc,10.00/304.8);// This is the elevation created earlier
// Use the previously mentioned method of creating a collector to get all the files
            FilteredElementCollector fil = new FilteredElementCollector(doc);
// Create a filter to filter out all view types
            fil.OfClass(typeof(ViewFamilyType));
// Traverse each view type
            foreach (ViewFamilyType vv in fil)
            {
// Find a view whose view type is floor or ceiling
                if (vv.ViewFamily == ViewFamily.FloorPlan || vv.ViewFamily == ViewFamily.CeilingPlan)
                {
// Create this view
                    ViewPlan View = ViewPlan.Create(doc, vv.Id, ll.Id);
                }
            }

Using the above pile of code, you can create the view corresponding to the elevation , Let's see the effect ：

We created both floor and ceiling views ,（ In fact, these two views cannot be at the same level , Here are all listed at the same time , You can use any view type you want to create .）

Xiaobian wants to use the positive mold turning process to write articles , Something else will be interspersed in the middle , Finally, I will write some cases , The road to code is still far away , Just put Dad ~~~

（ Xiaobian is a hard working dog in a design institute , The update is slow and the reply is slow , I hope you will understand .）
