Parameter server in ROS Mainly used in Realize data sharing between different nodes . The parameter server is then equivalent to a common container independent of all nodes , You can store data in this container , Called by different nodes , Of course, different nodes can also store data , The typical application scenarios of the parameter server are as follows :
When navigation is implemented , We'll do path planning , such as : Global path planning , Design an approximate path from the starting point to the target point . Local path planning , The travel path will be generated according to the current road conditions . Global path planning and local path planning , The parameter server will be used ： Path planning , It is necessary to refer to the size of the trolley , We can store these size information in the parameter server , Global path planning nodes and local path planning nodes can middle note these parameters from the parameter server. .
Parameter server , It is generally applicable to some application scenarios with data sharing , Similar to global variables .

1 Parameter server theoretical model

The implementation of parameter server is the simplest , The model is shown in the figure below , There are three roles involved in the model :

• ROS Master ( managers )
• Talker ( Parameter setter )
• Listener ( Parameter caller )
  ROS Master Save parameters as a public container ,Talker You can set parameters to the container ,Listener You can get parameters .

  The whole process is realized by the following steps :

1.1 Talker Set parameters

Talker adopt RPC Send parameters to the parameter server ( Including parameter name and parameter value ),ROS Master Save the parameter to the parameter list .

1.2 Listener To obtain parameters

Listener adopt RPC Send a parameter lookup request to the parameter server , The request contains the name of the parameter to be found .

1.3 ROS Master towards Listener Send parameter value

ROS Master Follow the steps 2 Request the parameter name provided to find the parameter value , And pass the query results through RPC Send to Listener.

1.4 Data type of parameter :

• 32-bit integers
• booleans
• strings
• doubles
• iso8601 data
• lists
• base64-encoded binary data
• Dictionaries

Be careful ： The parameter server is not designed for high performance , Therefore, it is best to store static non binary simple data

2 Parameter server operation (C++)

demand : Add, delete, change and query parameters of the parameter server , You can use two sets of API Realization :

• ros::NodeHandle
• ros::param

2.1 Parameter added to the server ( modify ) Parameters

/*  Addition and modification of parameter server operation ( both of them API equally )_C++ Realization :  stay  roscpp  Two sets of  API  Implement parameter operation  ros::NodeHandle setParam(" key ", value ) ros::param set(" key "," value ")  Example : Set the shaping parameters separately 、 floating-point 、 character string 、bool、 list 、 Dictionary and other type parameters   modify ( The same key , Different values ) */
#include "ros/ros.h"

int main(int argc, char *argv[])
{

    ros::init(argc,argv,"set_update_param");

    std::vector<std::string> stus;
    stus.push_back("zhangsan");
    stus.push_back(" Li Si ");
    stus.push_back(" Wang Wu ");
    stus.push_back(" Grandson big head ");

    std::map<std::string,std::string> friends;
    friends["guo"] = "huang";
    friends["yuang"] = "xiao";

    //NodeHandle--------------------------------------------------------
    ros::NodeHandle nh;
    nh.setParam("nh_int",10); // integer
    nh.setParam("nh_double",3.14); // floating-point
    nh.setParam("nh_bool",true); //bool
    nh.setParam("nh_string","hello NodeHandle"); // character string
    nh.setParam("nh_vector",stus); // vector
    nh.setParam("nh_map",friends); // map

    // Modify the presentation ( The same key , Different values )
    nh.setParam("nh_int",10000);

    //param--------------------------------------------------------
    ros::param::set("param_int",20);
    ros::param::set("param_double",3.14);
    ros::param::set("param_string","Hello Param");
    ros::param::set("param_bool",false);
    ros::param::set("param_vector",stus);
    ros::param::set("param_map",friends);

    // Modify the presentation ( The same key , Different values )
    ros::param::set("param_int",20000);

    return 0;
}

2.2 Get parameters from the parameter server

/*  Query of parameter server operation _C++ Realization :  stay  roscpp  Two sets of  API  Implement parameter operation  ros::NodeHandle param( key , The default value is )  There is , Return the corresponding result , Otherwise, return the default value  getParam( key , Variables that store results )  There is , return  true, And assign the value to the parameter 2  If the key does not exist , So the return value is zero  false, And not a parameter 2 assignment  getParamCached key , Variables that store results )-- Improve variable acquisition efficiency   There is , return  true, And assign the value to the parameter 2  If the key does not exist , So the return value is zero  false, And not a parameter 2 assignment  getParamNames(std::vector<std::string>)  Get all keys , And stored in the parameter  vector  in  hasParam( key )  Whether to include a key , There is returned  true, Otherwise return to  false searchParam( Parameters 1, Parameters 2)  The search button , Parameters 1 Is the key to be searched , Parameters 2 Variables that store search results  ros::param -----  And  NodeHandle  similar  */

#include "ros/ros.h"

int main(int argc, char *argv[])
{

    setlocale(LC_ALL,"");
    ros::init(argc,argv,"get_param");

    //NodeHandle--------------------------------------------------------
    /* ros::NodeHandle nh; // param  function  int res1 = nh.param("nh_int",100); //  Key exists  int res2 = nh.param("nh_int2",100); //  The key doesn't exist  ROS_INFO("param To get the results :%d,%d",res1,res2); // getParam  function  int nh_int_value; double nh_double_value; bool nh_bool_value; std::string nh_string_value; std::vector<std::string> stus; std::map<std::string, std::string> friends; nh.getParam("nh_int",nh_int_value); nh.getParam("nh_double",nh_double_value); nh.getParam("nh_bool",nh_bool_value); nh.getParam("nh_string",nh_string_value); nh.getParam("nh_vector",stus); nh.getParam("nh_map",friends); ROS_INFO("getParam Results obtained :%d,%.2f,%s,%d", nh_int_value, nh_double_value, nh_string_value.c_str(), nh_bool_value ); for (auto &&stu : stus) { ROS_INFO("stus  Elements :%s",stu.c_str()); } for (auto &&f : friends) { ROS_INFO("map  Elements :%s = %s",f.first.c_str(), f.second.c_str()); } // getParamCached() nh.getParamCached("nh_int",nh_int_value); ROS_INFO(" Get data through cache :%d",nh_int_value); //getParamNames() std::vector<std::string> param_names1; nh.getParamNames(param_names1); for (auto &&name : param_names1) { ROS_INFO(" Name resolution name = %s",name.c_str()); } ROS_INFO("----------------------------"); ROS_INFO(" There is  nh_int  Do you ? %d",nh.hasParam("nh_int")); ROS_INFO(" There is  nh_intttt  Do you ? %d",nh.hasParam("nh_intttt")); std::string key; nh.searchParam("nh_int",key); ROS_INFO(" The search button :%s",key.c_str()); */
    //param--------------------------------------------------------
    ROS_INFO("++++++++++++++++++++++++++++++++++++++++");
    int res3 = ros::param::param("param_int",20); // There is
    int res4 = ros::param::param("param_int2",20); //  Does not exist. Return to default
    ROS_INFO("param To get the results :%d,%d",res3,res4);

    // getParam  function
    int param_int_value;
    double param_double_value;
    bool param_bool_value;
    std::string param_string_value;
    std::vector<std::string> param_stus;
    std::map<std::string, std::string> param_friends;

    ros::param::get("param_int",param_int_value);
    ros::param::get("param_double",param_double_value);
    ros::param::get("param_bool",param_bool_value);
    ros::param::get("param_string",param_string_value);
    ros::param::get("param_vector",param_stus);
    ros::param::get("param_map",param_friends);

    ROS_INFO("getParam Results obtained :%d,%.2f,%s,%d",
            param_int_value,
            param_double_value,
            param_string_value.c_str(),
            param_bool_value
            );
    for (auto &&stu : param_stus)
    {

        ROS_INFO("stus  Elements :%s",stu.c_str());
    }

    for (auto &&f : param_friends)
    {

        ROS_INFO("map  Elements :%s = %s",f.first.c_str(), f.second.c_str());
    }

    // getParamCached()
    ros::param::getCached("param_int",param_int_value);
    ROS_INFO(" Get data through cache :%d",param_int_value);

    //getParamNames()
    std::vector<std::string> param_names2;
    ros::param::getParamNames(param_names2);
    for (auto &&name : param_names2)
    {

        ROS_INFO(" Name resolution name = %s",name.c_str());
    }
    ROS_INFO("----------------------------");

    ROS_INFO(" There is  param_int  Do you ? %d",ros::param::has("param_int"));
    ROS_INFO(" There is  param_intttt  Do you ? %d",ros::param::has("param_intttt"));

    std::string key;
    ros::param::search("param_int",key);
    ROS_INFO(" The search button :%s",key.c_str());

    return 0;
}

2.3 The parameter server deletes the parameter

/*  Parameter server operation deletion _C++ Realization : ros::NodeHandle deleteParam(" key ")  Delete the parameter according to the key , Delete successful , return  true, otherwise ( Parameter does not exist ), return  false ros::param del(" key ")  Delete the parameter according to the key , Delete successful , return  true, otherwise ( Parameter does not exist ), return  false */
#include "ros/ros.h"


int main(int argc, char *argv[])
{

    setlocale(LC_ALL,"");
    ros::init(argc,argv,"delete_param");

    ros::NodeHandle nh;
    bool r1 = nh.deleteParam("nh_int");
    ROS_INFO("nh  Delete result :%d",r1);

    bool r2 = ros::param::del("param_int");
    ROS_INFO("param  Delete result :%d",r2);

    return 0;
}
