Understanding of swin transformer network architecture and corresponding improvement modules

swin-Transformer

Transformer More and more fire , Personal feelings are based on Transformer It's amazing to use the matrix for vision ！！

Swin-Transformer Compare with VIT The way to improve ：

• SwinT Use similar CNN Middle level secondary construction method , In this way backbone It is helpful to build detection and segmentation tasks on this basis , and VIT It is a direct one-time down sampling 16 times , The following characteristic graphs keep the sampling rate unchanged .
• stay SwinT Use in Windows Multi-head Self-Attention（WMSA） The concept of , In the diagram above 4 Double down sampling and 8 Times down sampling , Divide the picture into multiple disjoint areas （window）, and Multi-head Self-Attention Only in each independent window In the operation , be relative to VIT Direct to global in window Conduct Multi-head Self-Attention, The purpose of this is to reduce the amount of calculation , although SwinT Proposed WMSA Have the ability to save calculation , But it's a different sacrifice window At the cost of information transmission between , So the author aims at WMSA The shortcomings of , Put forward Shifted Windows Multi-head Self-Attention（SW-MSA）, In this way, information can be transmitted in adjacent windows ！

SwinT The network architecture of

• First put the picture （H * W * C） Input to Patch Partition The module is divided into blocks , Quadruple sampling method , Wide and high /4, passageway * 16 , Re pass Linear Embedding layer , This layer also passes through conv Realized , The main function is to reduce the channel （H/4,W/4,16*C）—> (H/4,W/4,C)
• Then through four stage Build feature maps of different sizes , except stage1 Pass first Linear Embedding Out of layer , The other three. stage It's all through Patch Merging Layer down sampling , Then it's all stacked and repeated SwinT block, It can be downloaded from （b） see ,SwinT block There are two structures in it W-MSA and SW-MSA, Because these two structures are used in pairs , So you can see the stacked block Is an even number .
• Finally, for classified networks , Then there will be another Layer Norm layer , Global pooling layer and FC Layer to get the final output .

Next, we're going to talk about Patch Merging、W-MSA、SW-MSA And the relative position paranoia used （relative position bias） Explain in detail , and SwinT block Used in MLP The structure and VIT The structure is the same in

* Patch Merging Detailed explanation

Patch Merging Follow Yolov5 in focus The structure is similar , Every other pixel is a patch, So wide and high /2,C * 4, And then through a Layer Norm layer , Finally, a FC Layer in Feature Map The depth direction changes linearly （H/2,W/2,C*4）-> (H/2,W/2,C * 2) .

* W-MSA Detailed explanation

introduce Windows Multi-head Self-Attention Module is to reduce the amount of calculation , Realize the idea ： Is to divide a picture into multiple window,window Many points patch（ Pixels ）, Every patch Only in this part window In doing Multi-head Self-Attention. Be careful ： W-MSA Each of them window No information interaction .

* SW-MSA Detailed explanation

According to W-MSA in window There is no information interaction between them, which has been improved , Put forward SW-MSA.

As shown in the figure above , On the left W-MSA stay layer L Use ,SW-MSA It's in L+1 Layer using , Because from SwinT block You can see that they are used in pairs , The left and right windows can be compared （Windows） There's a shift , With this offset M/2 Pixel , This solves the problem that information cannot be exchanged between different windows ！！

window The number is before 4 Become what you are now 9 A the ！！！！！！！！！！！！！！！！！

Adopted by the author Efficient batch computation for shifted configuration This method of calculation , That is to say, put each in the right figure window Regroup into 4 individual window！ But one problem is that different regions carry different information , If forced to merge together, it is easy to cause information confusion , The author's solution is that if the pixels of the new region are not the pixels of the original region , In the calculation QK Then subtract 100, In this way softmax after , The connection between this part of pixels and other pixels is 0 了 ,** Be careful ：** After the calculation, you have to move the data back to the original position .

Detailed explanation of model parameter configuration

• win.sz 7 * 7 Indicates the window size

• dim Express feature map The depth of the passage （ Or it can be said that token Vector length of ）

• head Indicates that in the multi head attention module head Number
