The previous study refers to 《STM32 Beginner's Guide 》

---

One 、 To configure GPIO

LED The partial schematic diagram is shown in the figure below ：

Now configure LED0（PA8） This pin is illustrated as an example .

1. Define initialization structure variables

GPIO_InitTypeDef GPIO_InitStrcture;

Go to the definition of structure ：

typedef struct
{
  uint16_t GPIO_Pin;             /*!< Specifies the GPIO pins to be configured.
                                      This parameter can be any value of @ref GPIO_pins_define */

  GPIOSpeed_TypeDef GPIO_Speed;  /*!< Specifies the speed for the selected pins.
                                      This parameter can be a value of @ref GPIOSpeed_TypeDef */

  GPIOMode_TypeDef GPIO_Mode;    /*!< Specifies the operating mode for the selected pins.
                                      This parameter can be a value of @ref GPIOMode_TypeDef */
}GPIO_InitTypeDef;

2. Can make IO Port clock

// Can make PA The peripheral clock of
RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOA,ENABLE);

Go to function definition to learn , The first parameter of this function is used to specify which group to open IO The clock of the port , The second parameter is set to enable or disable .

3. To configure IO Port pin

// To configure PA The pin of the port
GPIO_InitStrcture.GPIO_Pin=GPIO_Pin_8;

4. To configure IO Port input / output mode

// Configured to output push-pull mode
GPIO_InitStrcture.GPIO_Mode=GPIO_Mode_Out_PP;

5. To configure IO Port output speed

// Can choose 10Mhz、20Mhz、50Mhz
GPIO_InitStrcture.GPIO_Speed=GPIO_Speed_50MHz;

6. Initialize the corresponding register

// initialization A Port corresponding register
GPIO_Init(GPIOA,&GPIO_InitStrcture);

LED0 and LED1 Two pin configuration

led.h

#ifndef __LED_H
#define __LED_H

#include "stm32f10x.h"

#define LED0_OFF GPIO_SetBits(GPIOA,GPIO_Pin_8)
#define LED0_ON GPIO_ResetBits(GPIOA,GPIO_Pin_8)
#define LED0_REV GPIO_WriteBit(GPIOA,GPIO_Pin_8,(BitAction)(1-GPIO_ReadOutputDataBit(GPIOA,GPIO_Pin_8)))

#define LED1_OFF GPIO_SetBits(GPIOB,GPIO_Pin_11)
#define LED1_ON GPIO_ResetBits(GPIOB,GPIO_Pin_11)
#define LED1_REV GPIO_WriteBit(GPIOB,GPIO_Pin_11,(BitAction)(1-GPIO_ReadOutputDataBit(GPIOB,GPIO_Pin_11)))


void LED_GPIO_Config(void);

#endif /*__LED_H */

led.c

#include "led.h"
#include "stm32f10x.h"

void LED_GPIO_Config(void)
{

	GPIO_InitTypeDef GPIO_InitStrcture;

	//set PA8
	RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOA,ENABLE);//clk

	GPIO_InitStrcture.GPIO_Pin=GPIO_Pin_8;							//Pin
	GPIO_InitStrcture.GPIO_Speed=GPIO_Speed_50MHz;			//speed
	GPIO_InitStrcture.GPIO_Mode=GPIO_Mode_Out_PP;				//mode

	GPIO_Init(GPIOA,&GPIO_InitStrcture);								//init

	//set PB11
	RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOB,ENABLE);//clk
	GPIO_InitStrcture.GPIO_Pin=GPIO_Pin_11;							//Pin
	GPIO_InitStrcture.GPIO_Speed=GPIO_Speed_50MHz;			//speed
	GPIO_InitStrcture.GPIO_Mode=GPIO_Mode_Out_PP;				//mode

	GPIO_Init(GPIOB,&GPIO_InitStrcture);								//init

}

Two 、 Key input control LED The light of the sun

1. Key input configuration

Key.h

#ifndef __KEY_H
#define __KEY_H


#define KEY1 GPIO_ReadInputDataBit(GPIOC,GPIO_Pin_1)
#define KEY2 GPIO_ReadInputDataBit(GPIOC,GPIO_Pin_13)
#define KEY3 GPIO_ReadInputDataBit(GPIOA,GPIO_Pin_0)

void Key_GPIO_Config(void);

unsigned char KEY_Scan(void);
unsigned char KEY1_Scan(void);
unsigned char KEY2_Scan(void);
unsigned char KEY3_Scan(void);

#endif /* __KEY_H */

Key.c

#include "stm32f10x.h"
#include "Key.h"
#include "delay.h"

void Key_GPIO_Config(void)
{

	GPIO_InitTypeDef GPIO_InitStructure;

	//PC
	RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOC,ENABLE);

	GPIO_InitStructure.GPIO_Pin=GPIO_Pin_1|GPIO_Pin_13;
	GPIO_InitStructure.GPIO_Mode=GPIO_Mode_IPU;

	GPIO_Init(GPIOC,&GPIO_InitStructure);

	//PA
	RCC_APB2PeriphClockCmd(RCC_APB2Periph_GPIOA,ENABLE);

	GPIO_InitStructure.GPIO_Pin=GPIO_Pin_0;
	GPIO_InitStructure.GPIO_Mode=GPIO_Mode_IPD;

	GPIO_Init(GPIOA,&GPIO_InitStructure);
}


unsigned char KEY_Scan(void)
{

	unsigned char key_code;
	if(KEY1_Scan()==1) key_code=1;
	else if(KEY2_Scan()==1) key_code=2;
	else if(KEY3_Scan()==1) key_code=3;
	else key_code=0;
	return key_code;
}

unsigned char KEY1_Scan(void)
{

	static char key_up1=0;
	if(KEY1==0)
	{

		Delay(10000);
		if(KEY1==0)
		{

			key_up1=1;
		}
	}
	if(KEY1==1&&key_up1==1)
	{

		key_up1=0;
		return 1;
	}
	return 0;
}

unsigned char KEY2_Scan(void)
{

	static char key_up2=0;

	if(KEY2==0)
	{

		Delay(10000);
		if(KEY2==0)
		{

			key_up2=1;
		}
	}
	if(KEY2==1&&key_up2==1)
	{

		key_up2=0;
		return 1;
	}
	return 0;
}


unsigned char KEY3_Scan(void)
{

	static char key_up3=0;

	if(KEY3==0)
	{

		Delay(10000);
		if(KEY3==0)
		{

			key_up3=1;
		}
	}
	if(KEY3==1&&key_up3==1)
	{

		key_up3=0;
		return 1;
	}
	return 0;
}

2. Realization function

When WK UP Press down ,LED0、LED1 At the same time, reverse ;
When KEY0 Press down ,LED0 Take the opposite ;
When KEY1 Press down ,LED1 Take the opposite .

The main function ：

#include "stm32f10x.h"
#include "led.h"
#include "Key.h"



int main(void)
{

	unsigned char value=0;

	LED_GPIO_Config();

	Key_GPIO_Config();

	while(1)
	{

		value =KEY_Scan();

		if(value==1)
		{

			LED0_REV;
		}
		else if(value==2)
		{

			LED1_REV;
		}
		else if(value==3)
		{

			LED0_REV;
			LED1_REV;
		}
	}
}

The learning

Mainly through training STM32GPIO Simplest configuration . Understand what the code is doing , And according to their own learning board to modify the code is the biggest progress in the near future , Continue to work hard .
