效果
介绍
实现折线图的大体思路和数学画图一致：先画底部刻度（底部描述），再画点，再连线。
关键字
1. 对象池
2. 迭代
3. DoTween 动画
分析及代码
定义绘图数据的结构GraphData，包含数据的描述信息_desc，数据的值_value。在需要绘图时传递一组GraphData的类型的数据给此模块就可以实现折线图的绘制。
[System.Serializable]
public struct GraphData
{
public string _desc;
[Range(0, 100)]
public float _value;
public float Rate
{
get
{
return _value / 100;
}
}
public GraphData(string desc, float value)
{
_desc = desc;
_value = value;
}
}
下图是Unity的布局，为了方便管理，在LineGraphPanel中分别设置了LeftSide（左侧刻度），DescContent（底部描述），DotContent（点），LineContent（线）四个空对象存放相应的子元素。
public GraphData[] _datas;//数据
public float _lineWidth = 3;//线宽
public float _dotRadius = 2;//点半径
public Transform _leftSide;//左侧描述
public RectTransform _descContent;//描述Content
public RectTransform _dotContent;//点Content
public RectTransform _lineContent;//线Content
public Text _descPrefab;//描述Prefab
public RectTransform _dotPrefab;//点Prefab
public Image _linePrefab;//线Prefab
public float _tweenTime = 1f;//动画时间
//描述、点、线 管理
private Text[] _descs;
private RectTransform[] _dots;
private Image[] _lines;
因为背景、左侧刻度是不会改变的，所以初始化左侧刻度的方法只需要在Start方法中调用一次就可以（背景我直接用的一张10条横线的图片）。
/// <summary>
/// 初始化折线图
/// </summary>
public void InitLineGraph(GraphData[] data)
{
//leftSide
for (int i = 0; i < _leftSide.childCount; i++)
{
_leftSide.GetChild(i).GetComponent<Text>().text = (100 - i * 10).ToString();
}
}
底部描述使用了Unity的自动布局组件，因为在下一步需要绘制时是需要用到这里的位置信息，所以需要在结尾处刷新UI的布局。其次，为了防止动态的刷新数据过于频繁，使用到了对象池的优化（链接）。
/// <summary>
/// 底部描述
/// </summary>
private void DrawDesc()
{
_descs = new Text[_datas.Length];
for (int i = 0; i < _datas.Length; i++)
{
Text desc = ObjectPool.Instance.GetObject(_descPrefab.name, _descContent).GetComponent<Text>();
desc.text = _datas[i]._desc;
desc.transform.SetAsLastSibling();//使用对象池和自动布局组件会调乱顺序，要重置
desc.gameObject.SetActive(true);
_descs[i] = desc;
}
LayoutRebuilder.ForceRebuildLayoutImmediate(_descContent);//使用自动布局组件要刷新UI，刷新位置
}
根据底部描述的位置、数据的值计算点的位置
/// <summary>
/// 画点
/// </summary>
private void DrawDot()
{
float height = _dotContent.rect.height;
_dots = new RectTransform[_datas.Length];
for (int i = 0; i < _datas.Length; i++)
{
RectTransform dot = ObjectPool.Instance.GetObject(_dotPrefab.name, _dotContent).GetComponent<RectTransform>();
dot.localPosition = new Vector3(_descs[i].transform.localPosition.x, height * (_datas[i].Rate - 0.5f), 0);//锚点在中心
dot.sizeDelta = Vector2.one * _lineWidth * 2;
dot.gameObject.SetActive(true);
_dots[i] = dot;
}
}
根据上一步的点生成线段，线段我使用的是Image，所以可以随意指定它的宽度，位置、旋转根据相邻的两点计算。这里为了实现动画，使用了DoTween和递归，在每生成完一条线后接着生成下一条。
/// <summary>
/// 画线
/// </summary>
private void DrawLines()
{
_lines = new Image[_datas.Length - 1];
DrawLine();
}
/// <summary>
/// 画线
/// </summary>
/// <param name="index"></param>
private void DrawLine(int index = 0)
{
if (index >= _lines.Length) return;
Vector2 curPos = _dots[index].localPosition;
Vector2 nextPos = _dots[index + 1].localPosition;
float length = Vector2.Distance(curPos, nextPos);
Vector3 dir = curPos - nextPos;
float angle = Vector3.Angle(Vector3.up, dir);
Vector2 center = (curPos + nextPos) / 2;
Image line = ObjectPool.Instance.GetObject(_linePrefab.name, _lineContent).GetComponent<Image>();
line.rectTransform.localEulerAngles = Vector3.forward * angle;
line.rectTransform.localPosition = center;
line.rectTransform.sizeDelta = new Vector2(_lineWidth, length);
line.gameObject.SetActive(true);
line.fillAmount = 0;
line.fillOrigin = dir.x > 0 ? 0 : 1;
line.DOFillAmount(1, _tweenTime / _lines.Length).OnComplete(() => DrawLine(index + 1));
_lines[index] = line;
}
using System.Collections;
using System.Collections.Generic;
using UnityEngine;
using UnityEngine.UI;
using DG.Tweening;
[System.Serializable]
public struct GraphData
{
public string _desc;
[Range(0, 100)]
public float _value;
public float Rate
{
get
{
return _value / 100;
}
}
public GraphData(string desc, float value)
{
_desc = desc;
_value = value;
}
}
/// <summary>
/// 折线图
/// </summary>
public class UILineGraphManager : MonoBehaviour
{
public GraphData[] _datas;//数据
public float _lineWidth = 3;//线宽
public float _dotRadius = 2;//点半径
public Transform _leftSide;//左侧描述
public RectTransform _descContent;//描述Content
public RectTransform _dotContent;//点Content
public RectTransform _lineContent;//线Content
public Text _descPrefab;//描述Prefab
public RectTransform _dotPrefab;//点Prefab
public Image _linePrefab;//线Prefab
public float _tweenTime = 1f;//动画时间
//描述、点、线 管理
private Text[] _descs;
private RectTransform[] _dots;
private Image[] _lines;
private void Awake()
{
ObjectPool.Instance.SetPrefab(_descPrefab.gameObject);
ObjectPool.Instance.SetPrefab(_dotPrefab.gameObject);
ObjectPool.Instance.SetPrefab(_linePrefab.gameObject);
}
/// <summary>
/// 初始化折线图
/// </summary>
public void InitLineGraph(GraphData[] data)
{
//leftSide
for (int i = 0; i < _leftSide.childCount; i++)
{
_leftSide.GetChild(i).GetComponent<Text>().text = (100 - i * 10).ToString();
}
RefeshLineGraph(data);
}
/// <summary>
/// 刷新折线图
/// </summary>
public void RefeshLineGraph(GraphData[] data)
{
_datas = data;
ClearTransform(_descContent);
ClearTransform(_dotContent);
ClearTransform(_lineContent);
DrawDesc();
DrawDot();
DrawLines();
}
/// <summary>
/// 底部描述
/// </summary>
private void DrawDesc()
{
_descs = new Text[_datas.Length];
for (int i = 0; i < _datas.Length; i++)
{
Text desc = ObjectPool.Instance.GetObject(_descPrefab.name, _descContent).GetComponent<Text>();
desc.text = _datas[i]._desc;
desc.transform.SetAsLastSibling();//使用对象池和自动布局组件会调乱顺序，要重置
desc.gameObject.SetActive(true);
_descs[i] = desc;
}
LayoutRebuilder.ForceRebuildLayoutImmediate(_descContent);//使用自动布局组件要刷新UI，刷新位置
}
/// <summary>
/// 画点
/// </summary>
private void DrawDot()
{
float height = _dotContent.rect.height;
_dots = new RectTransform[_datas.Length];
for (int i = 0; i < _datas.Length; i++)
{
RectTransform dot = ObjectPool.Instance.GetObject(_dotPrefab.name, _dotContent).GetComponent<RectTransform>();
dot.localPosition = new Vector3(_descs[i].transform.localPosition.x, height * (_datas[i].Rate - 0.5f), 0);//锚点在中心
dot.sizeDelta = Vector2.one * _lineWidth * 2;
dot.gameObject.SetActive(true);
_dots[i] = dot;
}
}
/// <summary>
/// 画线
/// </summary>
private void DrawLines()
{
_lines = new Image[_datas.Length - 1];
DrawLine();
}
/// <summary>
/// 画线
/// </summary>
/// <param name="index"></param>
private void DrawLine(int index = 0)
{
if (index >= _lines.Length) return;
Vector2 curPos = _dots[index].localPosition;
Vector2 nextPos = _dots[index + 1].localPosition;
float length = Vector2.Distance(curPos, nextPos);
Vector3 dir = curPos - nextPos;
float angle = Vector3.Angle(Vector3.up, dir);
Vector2 center = (curPos + nextPos) / 2;
Image line = ObjectPool.Instance.GetObject(_linePrefab.name, _lineContent).GetComponent<Image>();
line.rectTransform.localEulerAngles = Vector3.forward * angle;
line.rectTransform.localPosition = center;
line.rectTransform.sizeDelta = new Vector2(_lineWidth, length);
line.gameObject.SetActive(true);
line.fillAmount = 0;
line.fillOrigin = dir.x > 0 ? 0 : 1;
line.DOFillAmount(1, _tweenTime / _lines.Length).OnComplete(() => DrawLine(index + 1));
_lines[index] = line;
}
/// <summary>
/// 入池
/// </summary>
/// <param name="parent"></param>
private void ClearTransform(Transform parent)
{
for (int i = 1; i < parent.childCount; i++)
{
ObjectPool.Instance.RecycleObj(parent.GetChild(i).gameObject, parent);
}
}
}
初始化时调用InitLineGraph()，刷新数据时调用RefeshLineGraph()。下面是示例：
using UnityEngine;
public class UIGraphManager : MonoBehaviour
{
public UILineGraphManager _line;
private GraphData[] _datas;
private void Start()
{
RefeshData();
_line.InitLineGraph(_datas);
}
private void Update()
{
if (Input.GetKeyDown(KeyCode.R))
{
RefeshData();
_line.RefeshLineGraph(_datas);
}
}
/// <summary>
/// 刷新数据
/// </summary>
public void RefeshData()
{
_datas = new GraphData[8];
for (int i = 0; i < _datas.Length; i++)
{
_datas[i] = new GraphData("数据" + i, Random.Range(0, 100));
}
}
}
