HCIP2---静态路由、动态路由

[r4]dhcp en
[r4]dhcp enable
[r4]int g0/0/0
[r4-GigabitEthernet0/0/0]dhcp select interface
[r4]ip route-static 0.0.0.0 0 10.1.1.66



[r3]ospf 1 router
[r3]ospf 1 router-id 1.1.1.1
[r3-ospf-1]area 0
[r3-ospf-1-area-0.0.0.0]network 10.1.1.0 0.0.0.255
[r3-ospf-1-area-0.0.0.0]network 1.1.1.1 0.0.0.0

[r5]int g0/0/0
[r5-GigabitEthernet0/0/0]ip add 10.1.1.78 30
[r5-GigabitEthernet0/0/0]int g0/0/1
[r5-GigabitEthernet0/0/1]ip add 10.1.1.82 30
[r5-GigabitEthernet0/0/1]int
[r5-GigabitEthernet0/0/2]ip add 10.1.1.158 27
[r5]dhcp enable
Info: The operation may take a few seconds. Please wait for a moment.done.
[r5]int g4/0/0
[r5-GigabitEthernet4/0/0]dhcp select interface
[r5-GigabitEthernet4/0/0]q
[r5]ip pool b
Info: It’s successful to create an IP address pool.
[r5-ip-pool-b]net
[r5-ip-pool-b]netw .
[r5-ip-pool-b]network 10.1.1.128 mask 27
[r5-ip-pool-b]gat
[r5-ip-pool-b]gateway-list 10.1.1.158
[r5-ip-pool-b]sta
[r5-ip-pool-b]static-bind ip-
[r5-ip-pool-b]static-bind ip-address 10.1.1.130 mac
[r5-ip-pool-b]static-bind ip-address 10.1.1.130 mac-address 54
[r5-ip-pool-b]q
[r5]int g0/0/2
[r5-GigabitEthernet0/0/2]dhcp select global
