GIS practical tips (III) - how to add legend in CASS?

2022-04-23 13:02:00 【Gatulo book】

In the attached drawings of the schema , There is one on the right side of the frame “ legend ”,CASS Why not ？ How to solve ？


Schematic diagram screenshot

resolvent

CASS Only for the time being 5000-100000 The frame of the scale bar can output “ legend ”,500-2000 The frame of the scale bar , There is no legend for the time being .

  How to add

（1） Open the block file of the frame

start-up CASS, Command line input open, Open the two block files shown in the following figure .


（2） Add legend

Add the legend shown in the figure below on the right side of the frame . Save the file


（3） Check the effect of the legend

start-up CASS, Click menu “ Graphics processing - Standard sheet ”, If there is a legend on the outside of the frame , Note that the addition is successful .


summary

Actually CASS Standard frame of , Is the block file that calls the frame （ac50tk and ac45tk） Generated . Just on the block of this frame , Add the desired legend block , The effect of adding legend can be realized .
