order

I don't have time to write in detail today , Let's talk about the current demand scenario , I just want to insert the business operation log ,springCloud Environmental Science . then , Based on the results of my implementation , Let's say , Design has no formula , It's the foundation 、 Series connection of characteristics .

One 、 Design thinking

Through the analysis of , And find other groups of colleagues to learn from , The general design idea is not divided 3 class , as follows ：
1、 Based on the section AOP
2、 Based on events ,EventBus or SpringBus
3、 Based on message oriented middleware

Two 、 Trade-off process

1. Based on the section （ House ）

the reason being that springCloud Distributed scenarios , If cut , Then there is 2 A plan ：
A、 Each service handles all aspects by itself
I don't think everyone wants to , This means that every service has to have a set AOP Cut code , Too complicated , In addition, you may need to insert a composite business operation log in the later stage of the business . Then the transmission parameters and everything may need to be changed , To transfer parameters of the business interface , The change is too big , The risk is too high , And complicated , House .
B、 Cut in the gateway
What the gateway does is no longer pure , Loss of understanding , For the composite business operation log to be inserted , You may also face the need to modify the parameters of the business interface ... House

2. Based on events ,EventBus or SpringBus（ House ）

Let's start with the scene , this 2 For a single service springBoot, It must be very fragrant . But here we have to compare their differences , Lose the conclusion directly ：

Look at the official documents and you can roughly know , this 2 Neither way is suitable for SpringCloud Distributed scenarios .

3. Based on message oriented middleware

This is because the business operation log is a lightweight business scenario , Adopted redis Publish and subscribe to information .redis It has also been implemented before publishing and subscribing to , Here I will directly share the core code , With some business design .
RedisSubListenerConfig

import cn.hutool.core.util.ArrayUtil;
import com.fillersmart.fsihouse.commonservice.component.RedisReceiver;
import com.fillersmart.fsihouse.data.constant.ConstantsEnum.MsgType;
import java.util.ArrayList;
import java.util.Arrays;
import java.util.List;
import java.util.concurrent.CountDownLatch;
import org.apache.commons.lang3.StringUtils;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Bean;
import org.springframework.data.redis.connection.RedisConnectionFactory;
import org.springframework.data.redis.core.StringRedisTemplate;
import org.springframework.data.redis.listener.PatternTopic;
import org.springframework.data.redis.listener.RedisMessageListenerContainer;
import org.springframework.data.redis.listener.adapter.MessageListenerAdapter;
import org.springframework.stereotype.Component;

/** * redis Subscription listening configuration  * * @author zhengwen **/
@Component
public class RedisSubListenerConfig {


  @Value("${redis.msg.topics}")
  private String topics;

  /** *  Initialize listener  * * @param connectionFactory  Connection factory  * @param listenerAdapter  Monitor adapter  * @return redis Listening container  */
  @Bean
  RedisMessageListenerContainer container(RedisConnectionFactory connectionFactory,
      MessageListenerAdapter listenerAdapter) {

    RedisMessageListenerContainer container = new RedisMessageListenerContainer();
    container.setConnectionFactory(connectionFactory);
    List<PatternTopic> topicList = new ArrayList<>();

    // new PatternTopic(" Here is the name of the monitoring channel ")  The channel should be consistent with that of the publisher
    if (StringUtils.isNotBlank(topics)) {

      String[] topisArr = topics.split(",");
      if (ArrayUtil.isNotEmpty(topisArr)) {

        Arrays.stream(topisArr).forEach(c -> {

          PatternTopic topic = new PatternTopic(c);
          topicList.add(topic);
        });
      }
    }
    // Enumerate information channels
    Arrays.stream(MsgType.values()).forEach(m -> {

      PatternTopic topic = new PatternTopic(m.getType());
      topicList.add(topic);
    });
    container.addMessageListener(listenerAdapter, topicList);
    return container;
  }

  /** *  Binding message listener and receiving listener  * * @param redisReceiver redis recipient  * @return  Information monitoring adapter  */
  @Bean
  MessageListenerAdapter listenerAdapter(RedisReceiver redisReceiver) {

    // redisReceiver  Message Receiver
    // receiveMessage  The method after receiving the message
    return new MessageListenerAdapter(redisReceiver, "receiveMessage");
  }


  @Bean
  StringRedisTemplate template(RedisConnectionFactory connectionFactory) {

    return new StringRedisTemplate(connectionFactory);
  }

  /** *  Registered subscribers  * * @param latch CountDownLatch * @return RedisReceiver */
  @Bean
  RedisReceiver receiver(CountDownLatch latch) {

    return new RedisReceiver(latch);
  }

  /** *  Counter , Used to control threads  * * @return CountDownLatch */
  @Bean
  CountDownLatch latch() {

    // Number of times count specified  1
    return new CountDownLatch(1);
  }

}

RedisReceiver

import cn.hutool.json.JSONUtil;
import com.fillersmart.fsihouse.commonservice.service.CommonService;
import com.fillersmart.fsihouse.data.core.Result;
import com.fillersmart.fsihouse.data.vo.msgpush.RedisMsgVo;
import java.util.concurrent.CountDownLatch;
import javax.annotation.Resource;
import lombok.extern.slf4j.Slf4j;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Component;


/*** *  Message Receiver （ subscriber ）  It needs to be injected into springboot in  * @author zhengwen */
@Slf4j
@Component
public class RedisReceiver {


  private CountDownLatch latch;

  @Resource
  private CommonService commonService;

  @Autowired
  public RedisReceiver(CountDownLatch latch) {

    this.latch = latch;
  }


  /** *  The method executed after receiving the message of the channel  * * @param message */
  public void receiveMessage(String message) {

    // Here is the method to execute after receiving the channel's message
    log.info("common General services received redis Information :" + message);
    if (JSONUtil.isTypeJSON(message)) {

      RedisMsgVo redisMsgVo = JSONUtil.toBean(message,RedisMsgVo.class);
      Result<?> res = commonService.dealRedisMsg(redisMsgVo);
      log.info("--redis Message processing results :{}",JSONUtil.toJsonStr(res));
    }
    latch.countDown();
  }
}

The following is business related
dealRedisMsg Method

  @Override
  public Result<?> dealRedisMsg(RedisMsgVo redisMsgVo) {

    log.info("-- General Services common Handle redis news --");
    String queueName = redisMsgVo.getQueueName();
    if (StringUtils.isBlank(queueName)) {

      return ResultGenerator.genFailResult("redis The information queue name is empty ");
    }
    MsgType msgType = MsgType.getEnum(queueName);
    if (msgType == null) {

      return ResultGenerator.genFailResult(" Unknown redis Information queue name ");
    }
    String msgContent = redisMsgVo.getContent();
    switch (msgType) {

      case PAYED_MSG:
        // Post payment information

        break;
      case BUSINESS_OPERATE_LOG_MSG:
        // Business operation record
        if (JSONUtil.isTypeJSON(msgContent)) {

          BusinessOperateLogVo businessOperateLogVo = JSONUtil.toBean(msgContent,
              BusinessOperateLogVo.class);
          if (businessOperateLogVo == null) {

            log.error(" Business operation record {} Convert to null ", msgContent);
          } else {

            businessOperateLogService.addBusLog(businessOperateLogVo);
          }
        }
        break;
      default:
        break;
    }
    return ResultGenerator.genSuccessResult();
  }

addBusLog Method

  @Override
  @Async
  public Result<?> addBusLog(BusinessOperateLogVo businessOperateLogVo) {

    // Parameter checking
    Assert.notNull(businessOperateLogVo.getPlatform(), ResponseCodeI18n.PLATFORM_NULL.getMsg());
    Assert.notNull(businessOperateLogVo.getOperateUserId(),
        ResponseCodeI18n.OPERATE_USER_NULL.getMsg());
    Assert.notNull(businessOperateLogVo.getBusinessId(),
        ResponseCodeI18n.BUSINESS_ID_NULL.getMsg());
    Assert.notNull(businessOperateLogVo.getCompanyId(), ResponseCodeI18n.PROJECT_ID_NULL.getMsg());

    // Initial operator information
    initOperateUserName(businessOperateLogVo);

    // Initial business operation information
    BusinessOperateLog operateLog = initBusinseeOperateLog(businessOperateLogVo);

    businessOperateLogMapper.insert(operateLog);

    return ResultGenerator.genSuccessResult();
  }

Calling method

ThreadUtil.execAsync(() -> {

  // Asynchronously convert and send redis Information
  BusinessOperateVo businessOperateVo = new BusinessOperateVo(operateUserId.longValue(),DevicePlatformType.OPERATION_PC);
  // Contract operation records
  BusinessDataVo businessDataVo = new BusinessDataVo(JSONObject.parseObject(JSONObject.toJSONString(finalUserSubscribe)),
      BusinessDataType.SUBSCRIBE_DATA,BusinessOperateType.BACK_APPLY,BusinessType.SUBSCRIBE);
  businessOperateVo.getBusinessDataList().add(businessDataVo);
  // The log of the rent return document
  businessDataVo = new BusinessDataVo(JSONObject.parseObject(JSONObject.toJSONString(backApply)),
      BusinessDataType.BACK_APPLY_DATA, BusinessOperateType.BACK_APPLY,BusinessType.BACK_APPLY);
  businessOperateVo.getBusinessDataList().add(businessDataVo);
  businessOperateLogRpcService.convertLogSendToRedis(businessOperateVo);
});

Supplementary table structure

CREATE TABLE `business_operate_log` (
  `id` bigint(20) NOT NULL AUTO_INCREMENT,
  `company_id` int(11) DEFAULT NULL COMMENT ' project id',
  `operate_type` int(2) DEFAULT NULL COMMENT ' Operation type ',
  `operate_name` varchar(200) DEFAULT NULL COMMENT ' Operation name ',
  `operate_time` datetime DEFAULT NULL COMMENT ' Operating time ',
  `business_id` bigint(20) DEFAULT NULL COMMENT ' Business data primary key id',
  `business_type` int(2) DEFAULT NULL COMMENT ' Business types ',
  `operate_user_id` bigint(20) DEFAULT NULL COMMENT ' Operation user id',
  `operate_user_name` varchar(200) DEFAULT NULL COMMENT ' Name of operator （ redundancy ）',
  `platform` int(1) DEFAULT NULL COMMENT ' Source of operating platform ',
  `memo` varchar(500) DEFAULT NULL COMMENT ' remarks ',
  `create_by` int(11) DEFAULT NULL COMMENT ' founder id',
  `create_time` datetime DEFAULT NULL COMMENT ' Creation time ',
  `is_deleted` int(1) DEFAULT NULL COMMENT ' Whether or not to delete ,0 no ,1 yes ',
  PRIMARY KEY (`id`),
  KEY `business_operate_log_company_id_IDX` (`company_id`) USING BTREE,
  KEY `business_operate_log_business_type_IDX` (`business_type`) USING BTREE
) ENGINE=InnoDB AUTO_INCREMENT=246 DEFAULT CHARSET=utf8mb4 COMMENT=' Business logging ';

Screenshot of supplementary log storage

summary

1、ThreadUtil It's delicious （HuTool The toolkit ）, Asynchronous does not affect interface performance
2、 The business trigger point only needs to pay attention to the key transmission parameters of the business operation log
3、 Scenarios run through distributed scenarios
Okay , Time is tight , So I'm going to go over here , I hope that helps , If you have any questions, please leave a message .
