Notes on the development of kindergarten enrollment registration system based on WeChat applet

2022-08-08 14:48:00 【InfoQ】

开发背景

The core is the enrollment registration for the new semester and the new school year of kindergarten,

Taking into account the graphic display of the kindergarten environment（室内,室外,文娱,living, etc.）,Kindergarten Admissions Policy Answers,Latest dynamic news,Introduction to kindergarten recipes,Registration project poster sharing, etc,

The purpose is to facilitate the kindergarten to conveniently count the registration data of children,Reasonable control of the number of applicants,Parents of young children can fill in the basic information of their children,住址信息,Guardian information, etc（可自定义设置）,

The garden staff can do pre-review based on the information,And prompt the user to modify and improve the information,And can view and export the listExcel,审核报名记录等,The labor cost of on-site registration is greatly reduced,Digital means improve work efficiency, It also saves time for parents.

功能图

技术运用

本项目使用微信小程序平台进行开发.

使用腾讯专门的小程序云开发技术,云资源包含云函数,数据库,带宽,存储空间,定时器等,资源配额价格低廉,无需域名和服务器即可搭建.

小程序本身的即用即走,适合小工具的使用场景,也适合快速开发迭代.

云开发技术采用腾讯内部链路,没有被黑客攻击的风险,安全性高且免维护.

资源承载力可根据业务发展需要随时弹性扩展.

数据库设计

报名项目表

EnrollModel.DB_STRUCTURE = {
 _pid: 'string|true',
 ENROLL_ID: 'string|true',

 ENROLL_TITLE: 'string|true|comment=标题',
 ENROLL_STATUS: 'int|true|default=1|comment=状态 0=未启用,1=使用中',

 ENROLL_CATE_ID: 'string|true|default=0|comment=分类',
 ENROLL_CATE_NAME: 'string|false|comment=分类冗余',

 ENROLL_CANCEL_SET: 'int|true|default=1|comment=取消设置 0=不允,1=允许,2=仅截止前可取消,3=It cannot be cancelled after review',
 ENROLL_EDIT_SET: 'int|true|default=1|comment=修改 0=不允,1=允许,2=仅截止前可,3=It cannot be modified after review',
 ENROLL_CHECK_SET: 'int|true|default=0|comment=审核 0=不需要审核,1=需要审核',

 ENROLL_MAX_CNT: 'int|true|default=20|comment=人数上限 0=不限',
 ENROLL_START: 'int|false|comment=开始时间',
 ENROLL_END: 'int|false|comment=截止时间',

 ENROLL_ORDER: 'int|true|default=9999',
 ENROLL_VOUCH: 'int|true|default=0',

 ENROLL_FORMS: 'array|true|default=[]',
 ENROLL_OBJ: 'object|true|default={}',

 ENROLL_JOIN_FORMS: 'array|true|default=[]',

 ENROLL_QR: 'string|false',
 ENROLL_VIEW_CNT: 'int|true|default=0',
 ENROLL_JOIN_CNT: 'int|true|default=0',

 ENROLL_ADD_TIME: 'int|true',
 ENROLL_EDIT_TIME: 'int|true',
 ENROLL_ADD_IP: 'string|false',
 ENROLL_EDIT_IP: 'string|false',
};

User registration form

EnrollJoinModel.DB_STRUCTURE = {
 _pid: 'string|true',
 ENROLL_JOIN_ID: 'string|true',
 ENROLL_JOIN_ENROLL_ID: 'string|true|comment=报名PK',

 ENROLL_JOIN_IS_ADMIN: 'int|true|default=0|comment=是否管理员添加 0/1',

 ENROLL_JOIN_USER_ID: 'string|true|comment=用户ID',
 ENROLL_JOIN_FORMS: 'array|true|default=[]|comment=表单',

 ENROLL_JOIN_STATUS: 'int|true|default=1|comment=状态 0=待审核 1=报名成功, 99=审核未过',
 ENROLL_JOIN_REASON: 'string|false|comment=审核拒绝或者取消理由',

 ENROLL_JOIN_LAST_TIME: 'int|true|default=0',

 ENROLL_JOIN_ADD_TIME: 'int|true',
 ENROLL_JOIN_EDIT_TIME: 'int|true',
 ENROLL_JOIN_ADD_IP: 'string|false',
 ENROLL_JOIN_EDIT_IP: 'string|false',
};

核心逻辑

async enrollJoin(userId, enrollId, forms) {

 // Whether the registration is over
 let whereEnroll = {
 _id: enrollId,
 ENROLL_STATUS: EnrollModel.STATUS.COMM
 }
 let enroll = await EnrollModel.getOne(whereEnroll);
 if (!enroll)
 this.AppError('该' + ENROLL_NAME + 'does not exist or has been discontinued');

 // Whether to start registration
 if (enroll.ENROLL_START > this._timestamp)
 this.AppError('该' + ENROLL_NAME + '尚未开始');

 // Whether the registration deadline has passed
 if (enroll.ENROLL_END < this._timestamp)
 this.AppError('该' + ENROLL_NAME + '已经截止');


 // 人数是否满
 if (enroll.ENROLL_MAX_CNT > 0) {
 let whereCnt = {
 ENROLL_JOIN_ENROLL_ID: enrollId,
 ENROLL_JOIN_STATUS: ['in', [EnrollJoinModel.STATUS.WAIT, EnrollJoinModel.STATUS.SUCC]]
 }
 let cntJoin = await EnrollJoinModel.count(whereCnt);
 if (cntJoin >= enroll.ENROLL_MAX_CNT)
 this.AppError('该' + ENROLL_NAME + '人数已满');
 }

 // whether you have already registered
 let whereMy = {
 ENROLL_JOIN_USER_ID: userId,
 ENROLL_JOIN_ENROLL_ID: enrollId,
 ENROLL_JOIN_STATUS: ['in', [EnrollJoinModel.STATUS.WAIT, EnrollJoinModel.STATUS.SUCC]]
 }
 let my = await EnrollJoinModel.getOne(whereMy);
 if (my) {
 if (my.ENROLL_JOIN_STATUS == EnrollJoinModel.STATUS.WAIT)
 this.AppError('You have already filled in,正在等待审核,No need to refill');
 else
 this.AppError('You have filled in successfully,No need to refill');
 }

 // 入库
 let data = {
 ENROLL_JOIN_USER_ID: userId,
 ENROLL_JOIN_ENROLL_ID: enrollId,
 ENROLL_JOIN_STATUS: (enroll.ENROLL_CHECK_SET == 0) ? EnrollJoinModel.STATUS.SUCC : EnrollJoinModel.STATUS.WAIT,
 ENROLL_JOIN_FORMS: forms
 }

 let enrollJoinId = await EnrollJoinModel.insert(data);

 // 统计数量
 this.statEnrollJoin(enrollId);

 let check = enroll.ENROLL_CHECK_SET;

 return { enrollJoinId, check }

 }
