Lead to

1 Tencent cloud server
2 Connect liunx Tools （mobexterm Address . change free version）
3 mysql Connection tool （navicat.exe）
4 RUOYI Source code Address Front and rear separated version
5 IDEA （ compile java ）
6 Visual Studio Code （ compile vue）

Tencent cloud configuration

1 Server preparation

1.1 Tencent cloud purchase address ：

Tencent cloud purchase address
Just buy the cheapest one ,2022 year 1 month 2 Japan price is 38¥

1.2 To configure

Just choose the universal type

Open ports

1 to open up MySQL Port number 3306

2 Software installation

The software is installed uniformly in /usr/local/* Next

2.1 MySQL Online installation

	cd  To   /usr/local/ perform

cd /usr/local/
yum update
 download
wget http://repo.mysql.com/mysql-community-release-el7-5.noarch.rpm
sudo rpm -ivh mysql-community-release-el7-5.noarch.rpm
yum update
 install
yum install mysql-server
systemctl start mysqld
 Run the following script file
mysql_secure_installation
 prompt root password , For the initial null, Press enter to set root It's a password
 Then prompt a series of questions , Choose according to your needs y  perhaps  n

To configure

#1. take my-default.cnf  copy to  /etc/my.cnf  Find your own directory according to the situation
cp /usr/share/doc/mysql-community-server-5.6.31/my-default.cnf  /etc/my.cnf
#2. edit /usr/my.cnf stay [client]( If not, add it yourself ) Add... Below
default-character-set = utf8
#3. edit /usr/my.cnf stay [mysqld] Add... Below
character_set_server =  utf8
#4. restart MySql service   This code is the same as the one used before net start mysql The effect should be the same   Opening service  centos7 Use the following code
systemctl restart  mysql.service
#5. Reproduce connection mysql And check the code as follows ：
mysql -uroot –proot
mysql>show variables like '%character%';

Allow remote login

GRANT ALL PRIVILEGES ON *.* TO 'root'@'%' IDENTIFIED BY 'root';
FLUSH PRIVILEGES;

Installation configuration completed
Local nvicat Connect

2.2 Redis install

Get into cd /usr/local/

cd /usr/local/
 download
wget http://download.redis.io/releases/redis-4.0.7.tar.gz
 decompression redis
tar -zxvf redis-4.0.7.tar.gz
 Get into src Next
cd /usr/local/redis-4.0.9/src/
 perform
make all
 Get into
/usr/local/redis-4.0.9/src
 start-up
./redis-server

 Get into
 ./redis-cli

2.3 ngnix install

cd /usr/local/

 download
sudo rpm -Uvh http://nginx.org/packages/centos/7/noarch/RPMS/nginx-release-centos-7-0.el7.ngx.noarch.rpm
 install
sudo yum install -y nginx

 Start stop
sudo systemctl start nginx.service
sudo systemctl enable nginx.service
 see
 ps -ef | grep nginx
 [root@VM-24-14-centos src]# ps -ef | grep nginx
root     13190     1  0 11:00 ?        00:00:00 nginx: master process /usr/sbin/nginx -c /etc/nginx/nginx.conf
nginx    13191 13190  0 11:00 ?        00:00:00 nginx: worker process
root     30401 23553  0 16:39 pts/0    00:00:00 grep --color=auto nginx

 To configure
vim /etc/nginx/nginx.conf
 take server  Whole replacement


listen       80;
        server_name  localhost;

        location / {

            root   /usr/local/nginx/html/dist;
            index  index.html index.htm;
        }


        location /prod-api/ {

            proxy_pass http://127.0.0.1:8080/;
        }

     # location
        # root:  According to the received resources /usr/local/nginx/html/dist Folder to find resources
        # index:  By default, go to the above path to find index.html perhaps index.htm
        error_page   500 502 503 504  /50x.html;
        location = /50x.html {

            root   html;
        }

2.4 jdk install

baidu There are many on the, just find an installation , Search keywords 《 install CentOS Lower installation JDK》

2.5 maven

baidu There are many on the, just find an installation , Search keywords 《 install CentOS Lower installation maven 》

3 The software runs

3.1 pack java

1 download Source code https://gitee.com/y_project/RuoYi-Vue.git
2 idea Open configuration
3 skip test

4 instal

5 package

6 Check the bag

7 Upload server
stay 、usr/local/ newly build xjl

cd /usr/local/
mkdir xjl

Just drag the bag over

8 start-up

cd /usr/local/xjl/
nohup java -jar ruoyi-admin.jar &
tail -200f nohup.out

3.1 pack vue

vscode open vue
pack

npm  install
npm run build:prod

The entire folder is compressed and uploaded to
/usr/local/nginx/html

decompression

cd  /usr/local/nginx/html
unzip -o dist.zip

4 success

Common command summary

nginx
systemctl stop nginx
systemctl start nginx
systemctl reload nginx

mysql
service mysqld start
service mysqld stop

Problem summary

Written after installation , The problem mainly focuses on the installation linux Software aspect
It's best to use online installation

If the problem still cannot be solved, please contact me
