Escape analysis

Memory escape ： The phenomenon that the memory on the stack escapes to the heap is called memory escape

Concept

The program confirms which variables are allocated in the stack area according to the code in the compilation stage , Which variables are allocated in the heap . This prevents too much memory from being allocated on the heap , reduce GC Pressure and procedure STW Time for

principle

• Pointers to stack objects cannot be stored in the heap

• A pointer to a stack object cannot exceed the lifetime of the object , That is, the pointer cannot survive after the stack object is destroyed

How to view

By compiling the code in the following way, you can see the escape analysis

go build -gcflags='-m -m -l'

• -m -m You can see all compiler optimizations
• -l Disable inline optimization

Analyze examples

Function returns a pointer to a local variable

package main

type st struct {

    a int
    b int
}

func Add(x, y int) *st {

    r := st{
    a: x, b: y}
    return &r
}

func main() {

    res := Add(3, 5)
    res.a = 10
}

See the escape analysis results

$ go build -gcflags="-m -m -l" test.go
# command-line-arguments
./test.go:9:2: r escapes to heap:
./test.go:9:2:   flow: ~r2 = &r:
./test.go:9:2:     from &r (address-of) at ./test.go:10:9
./test.go:9:2:     from return &r (return) at ./test.go:10:2
./test.go:9:2: moved to heap: r
note: module requires Go 1.17

You can see the local variable pointer r Memory escape occurred

Function returns a local variable

package main

type st struct {

    a int
    b int
}

func Add(x, y int) st {

    r := st{
    a: x, b: y}
    return r
}

func main() {

    res := Add(3, 5)
    res.a = 10
}

Escape analysis

$ go build -gcflags="-m -m -l" test.go
$

• There is no information , It means there is no escape

interface Type escape

package main

import "fmt"

func main() {

    res := 10
    fmt.Print(res)
}

Escape analysis

$ go build -gcflags="-m -m -l" test.go
# command-line-arguments
./test.go:7:11: res escapes to heap:
./test.go:7:11:   flow: {
    storage for ... argument} = &{
    storage for res}:
./test.go:7:11:     from res (spill) at ./test.go:7:11
./test.go:7:11:     from ... argument (slice-literal-element) at ./test.go:7:11
./test.go:7:11:   flow: {
    heap} = {
    storage for ... argument}:
./test.go:7:11:     from ... argument (spill) at ./test.go:7:11
./test.go:7:11:     from fmt.Print(... argument...) (call parameter) at ./test.go:7:11
./test.go:7:11: ... argument does not escape
./test.go:7:11: res escapes to heap
note: module requires Go 1.17

You can see res There was an escape , This is because ：

• The compiler is hard to determine interface{} Specific types of , So there will be an escape

But we can see that res There is no such thing as move to heap, This is because the compiler just puts res The stored value is stored in the heap ,res Itself is still in the stack area , But we can make the following changes ：

package main

import "fmt"

func main() {

    res := 10
    fmt.Print(&res)
}

Escape analysis

$ go build -gcflags="-m -m -l" test.go
# command-line-arguments
./test.go:6:2: res escapes to heap:
./test.go:6:2:   flow: {
    storage for ... argument} = &res:
./test.go:6:2:     from &res (address-of) at ./test.go:7:12
./test.go:6:2:     from &res (interface-converted) at ./test.go:7:12
./test.go:6:2:     from ... argument (slice-literal-element) at ./test.go:7:11
./test.go:6:2:   flow: {
    heap} = {
    storage for ... argument}:
./test.go:6:2:     from ... argument (spill) at ./test.go:7:11
./test.go:6:2:     from fmt.Print(... argument...) (call parameter) at ./test.go:7:11
./test.go:6:2: moved to heap: res
./test.go:7:11: ... argument does not escape
note: module requires Go 1.17

Will find ,res They also escaped to the pile area , This is because fmt.Print The output is res The address of , Therefore, the compiler will store the value of the address in the heap , But objects on the heap cannot store an address on the stack , Because after the stack variable is destroyed , Its address is invalid , The address stored in that heap will also be invalid , Therefore, it is necessary to res Also escaped to the pile area .

Escape from closure

package main

func add() func() int {

    num := 0
    f := func() int {

        num++
        return num
    }
    return f
}

func main() {

    add()
}

Escape analysis ：

$ go build -gcflags="-m -m -l" test.go
# command-line-arguments
./test.go:6:3: add.func1 capturing by ref: num (addr=true assign=true width=8)
./test.go:5:7: func literal escapes to heap:
./test.go:5:7:   flow: f = &{
    storage for func literal}:
./test.go:5:7:     from func literal (spill) at ./test.go:5:7
./test.go:5:7:     from f := func literal (assign) at ./test.go:5:4
./test.go:5:7:   flow: ~r0 = f:
./test.go:5:7:     from return f (return) at ./test.go:9:2
./test.go:4:2: num escapes to heap:
./test.go:4:2:   flow: {
    storage for func literal} = &num:
./test.go:4:2:     from func literal (captured by a closure) at ./test.go:5:7
./test.go:4:2:     from num (reference) at ./test.go:6:3
./test.go:4:2: moved to heap: num
./test.go:5:7: func literal escapes to heap
note: module requires Go 1.17

You can see f And in closures num Memory escapes have occurred . Because a function is also a pointer type , Therefore, as a return value, escape also occurs . And as long as you call f, Will call num, therefore num You also need to escape to the pile area

Variable size is uncertain or stack space is insufficient

• When the stack space is enough , There will be no escape , But when the variable is too large , Has completely exceeded the size of the stack space , There will be an escape to the heap to allocate memory
• When initializing slices , No size is specified directly , Instead, fill in the variables , In this case, in order to ensure the safety of memory , The compiler also triggers an escape , Allocate memory on the heap

towards channel Send pointer data

package main

func main() {

    ch1 := make(chan *int, 1)
    y := 5
    py := &y
    ch1 <- py
}

Escape analysis

$ go build -gcflags="-m -m -l" test.go
# command-line-arguments
./test.go:5:2: y escapes to heap:
./test.go:5:2:   flow: py = &y:
./test.go:5:2:     from &y (address-of) at ./test.go:6:8
./test.go:5:2:     from py := &y (assign) at ./test.go:6:5
./test.go:5:2:   flow: {heap} = py:
./test.go:5:2:     from ch1 <- py (send) at ./test.go:7:6
./test.go:5:2: moved to heap: y
note: module requires Go 1.17

The compiler cannot know channel The data in will be used by goroutine receive , There is no way to know when to release

summary

• Escape analysis determines which variables can be allocated on the stack at the compilation stage , Which variables are allocated on the heap
• To reduce the GC pressure , The running speed of the provider
• When the memory on the stack is used up, you don't need GC Handle , When the memory on the heap is used up, it will be handed over to GC Handle
• Minimize escape code , reduce GC pressure
