当前位置:网站首页>opencv应用——以图拼图
opencv应用——以图拼图
2022-04-23 20:49:00 【csuzhucong】
一,准备图片
可以先手动分一分,有的是关键信息在中间,有的是在上面,主要就是这两种。
然后用程序先截出正方形的图片:
int main()
{
for (int i = 1; i <= 10; i++) {
Mat img = imread("D:/pic2/img (" + to_string(i) + ").jpg",0);
int p = min(img.rows, img.cols);
Mat img2 = img(Rect((img.cols - p) / 2, (img.rows - p) / 2, p, p));
imwrite("D:/pic2/a" + to_string(i) + ".jpg",img2);
}
return 0;
}
截上面的:
int main()
{
for (int i = 1; i <= 15; i++) {
Mat img = imread("D:/pic2/img (" + to_string(i) + ").jpg",0);
int p = min(img.rows, img.cols);
Mat img2 = img(Rect(0, 0, p, p));
imwrite("D:/pic2/a" + to_string(i) + ".jpg",img2);
}
return 0;
}
二,拼图
我们先把所有小图调整到统一的大小,然后按照亮度排序。
对于目标图像,按照分块,也分别统计亮度排序。
再根据排序结果进行匹配,把小图往对应位置填充就行了。
图片除了要做亮度匹配之外,在最后拼到大图上之前,还要做亮度调整,把整体亮度调到和分块亮度相同。
struct Nodes
{
int t;
int id;
bool operator<(Nodes a) const
{
if (t == a.t)return id < a.id;
return t < a.t;
}
};
int imageSum(Mat img)
{
int s = 0;
for (int i = 0; i < img.rows; i++)for (int j = 0; j < img.cols; j++)
s += img.at<uchar>(i, j);
return s;
}
int main()
{
const int N = 9;
const int NUM = N * N;
const int SIZE = N * 2000;
const int PIX = 100;
const int R1 = SIZE / PIX;
const int R = R1 / N * R1 / N;
Mat imgs[NUM];
for (int i = 1; i <= NUM; i++) {
imgs[i - 1] = imread("D:/pic2/img (" + to_string(i) + ").jpg", 0);
resize(imgs[i - 1], imgs[i - 1], Size(PIX, PIX));
}
Mat img = imread("D:/pic2/img (74).jpg", 0);
resize(img, img, Size(SIZE, SIZE));
Nodes node[NUM * R];
Nodes node2[NUM * R];
for (int i = 0; i < NUM * R; i++) {
node[i].t = imageSum(imgs[i % NUM]);
node[i].id = i % NUM;
node2[i].t = imageSum(img(Rect(i % R1 * PIX, i / R1 * PIX, PIX, PIX)));
node2[i].id = i;
}
sort(node, node + NUM * R);
sort(node2, node2 + NUM * R);
for (int i = 0; i < NUM * R; i++)
{
Mat image;
imgs[node[i].id % NUM].copyTo(image);
image *= 1.0 * node2[i].t / node[i].t;
image.copyTo(img(Rect(node2[i].id % R1 * PIX, node2[i].id / R1 * PIX, PIX, PIX)));
}
//imshow("img", img);
imwrite("D:/pic2/ans.png", img);
cv::waitKey(0);
return 0;
}
拼接结果:
(头部)放大效果:
(眼睛)放大效果:
三,优化思路
1,当前所用图片较少,如果图片多一点,效果会好一点。
2,因为图片少,每个图片都被用到多次。当前是每个图片被使用的次数相同,这一点可以优化一下,自适应的选择每个图片被使用的次数,效果应该会更好。
3,要想搞成彩色的,主要问题在于图片的匹配问题。灰度图像只需要按照亮度排序即可匹配,改成彩色图像相当于从一维变成三维。
